- 58 -
GA-8ID2003 Series Motherboard
English
Flash BIOS Method Introduction
A. What is Q-Flash Utility?
Q-Flash utility is a pre-O.S. BIOS flash utility enables users to update its BIOS within BIOS
mode, no more fooling around any OS.
B. How to use Q-Flash?
a. After power on the computer, pressing <Del> immediately during POST (Power On Self Test) it
will allow you to enter AWARD BIOS CMOS SETUP, then press <F8> to enter Q-Flash utility.
CMOS Setup Utility-Copyright (C) 1984-2003 Award Software
}Standard CMOS Features Load Fail-Safe Defaults
}Advanced BIOS Features Load Optimized Defaults
}Integrated Peripherals Set Supervisor Password
}Power Management Setup Set User Password
}PnP/PCI Configurations Save & Exit Setup
}Frequency/Voltage Control Exit Without Saving
Top Perform ance
ESC:Quit higf:Select Item
F8: Q-Flash F10:Save & Exit Setup
Tim e, Date, Hard Disk Type...
Enter Q-Flash Utility (Y/N)? Y
b. Q-Flash Utility
Method 1 : Q-Flash
Q-Flash Utility V1.30
Flash Type/Size : SST 39SF020 / 256K
Enter: Run hi: Move ESC: Reset F10: Power OFF
Keep DMI Data Enabled
Load BIOS from Floppy
Save BIOS to Floppy
8id2003_2002_t.p65 2003/3/14, 上午 11:1858
