ID Card Printer – User Manual

- 10 -

Installing to Ethernet (continued)

10. Ensure that the “I

nstall driver ready

for USB” option is NOT

selected, then

press ‘N

ext >’

11. Select the select the IP port you have

just created, then press ‘N

ext >

Now wait while the Driver files are installed and

created.

12. On successful installation, select “F

inish”

 It is recommended that you test the new

driver installation by printing a Windows

Test Page from the ‘General’ tab of the

Printer Driver Properties – the Windows Logo

should be printed in the centre of the card.

(Please see Section 11 – Printer Driver

Settings – for a detailed explanation of each

setting).
