Magicard Rio Pro [22/33] Cleaning supplies

ID Card Printer – User Manual

- 22 -

Cleaning supplies

Two cleaning cards and a cleaning roller (sleeve & bar) ar

e bundled with each new ID Card Printer.

You can also purchase additional cleaning kits, which include cleaning cards, rollers and pens:-

 Cleaning Kit

(10 cards, 1 pen) - Part number - 3633-0053

 Cleaning Roller Kit (5 sleeves, 1 roller bar) - Part number - 3633-0054

Cleaning the printer rollers with the Cleaning Card

To prevent the PVC c

ards slipping on the rollers during printing, we recommend that you

clean your printer using a cleaning card each time you replace the dye-film.
