Magicard Rio Pro [12/33] Front display panel

ID Card Printer – User Manual

- 12 -

The front display panel has a text display and 4 push buttons. These buttons act as ‘soft’ buttons –

i.e. their function varies depending on the text displayed immediately above each button.

The menu options for the soft buttons are explained in the following pages…

Front display panel

Switches the printer OFF.

To switch the printer back ON again - press any button.

Off button

Text Displa

Menu select

Buttons
