Magicard Rio Pro [26/33] Available consumables

ID Card Printer – User Manual

- 26 -

AVAILABLE CONSUMABLES

Pro

duct Code

Description

Dye film

 **300YMCKO YMCKO 5 panel dye

film, 300 images.

 **250YMCKOK YMCKOK 6 panel dye film, 250 images.

 **600KO - KO 2 panel black resin dye film, 600 images.

 **100

0K - Monochrome black resin, 1000 images.

(Various monochrom

e colors available).

(** = 2 di

git supplier code)

Pro

duct Code

Description

Cleanin

g Kit

 3633-0

053 - Contains 10 cleaning cards and 1 pen.

 3633-0

054 - Contains 5 cleaning roller sleeves and

1 roller bar.

Cards

 All standard PVC I

SO CR80 sized cards.

 HoloPatch

®/Magstripe cards are available.

Card thickness: 0.51mm

to 1.02mm (20mil to 40mil)
