4 Capacity tables
4 - 1 Cooling capacity tables
Air temperature (°C DB - °C WB) 22-16
Water temperature (Entering °C - Leaving °C)
6-11 7-12 8-13 9-14
Model
Air Flow
m
3
/hr
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
FWF02AT
663 1.73 1.73 0.30 40.81 1.63 1.63 0.28 37.19 1.53 1.53 0.26 33.63 1.43 1.43 0.25 30.30
630 1.65 1.65 0.28 37.88 1.56 1.56 0.27 34.58 1.46 1.46 0.25 31.33 1.37 1.37 0.24 28.28
595 1.54 1.54 0.27 34.25 1.46 1.46 0.25 31.33 1.37 1.37 0.24 28.46 1.28 1.28 0.22 25.76
FWF03AT
663 3.14 2.74 0.54 41.93 2.85 2.61 0.49 35.32 2.50 2.48 0.43 27.97 2.34 2.34 0.40 24.88
630 2.91 2.59 0.50 36.75 2.65 2.46 0.46 31.01 2.34 2.34 0.40 24.86 2.21 2.21 0.38 22.55
595 2.80 2.42 0.48 34.25 2.55 2.30 0.44 28.93 2.24 2.19 0.38 23.02 2.07 2.07 0.36 20.13
FWF04AT
731 3.17 2.92 0.54 41.49 2.85 2.75 0.49 34.32 2.60 2.60 0.45 29.13 2.46 2.46 0.42 26.12
695 3.06 2.78 0.53 38.95 2.75 2.62 0.47 32.21 2.48 2.48 0.43 26.63 2.34 2.34 0.40 23.87
663 2.95 2.65 0.51 36.52 2.65 2.50 0.46 30.19 2.36 2.36 0.41 24.45 2.23 2.23 0.38 21.91
Air temperature (°C DB - °C WB) 25-18
Water temperature (Entering °C - Leaving °C)
6-11 7-12 8-13 9-14
Model
Air Flow
m
3
/hr
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
FWF02AT
663 2.23 1.84 0.38 61.96 2.07 1.75 0.36 54.71 1.83 1.65 0.32 44.52 1.59 1.55 0.27 35.53
630 2.06 1.75 0.36 54.51 1.92 1.67 0.33 48.24 1.70 1.57 0.29 39.43 1.48 1.47 0.25 31.65
595 1.93 1.64 0.33 48.86 1.80 1.56 0.31 43.33 1.59 1.47 0.27 35.57 1.38 1.38 0.24 28.72
FWF03AT
663 3.98 2.89 0.69 64.73 3.68 2.76 0.63 56.02 3.35 2.63 0.58 46.87 3.01 2.49 0.52 38.57
630 3.70 2.73 0.64 56.56 3.42 2.61 0.59 48.99 3.11 2.48 0.54 41.04 2.80 2.35 0.48 33.84
595 3.55 2.55 0.61 52.61 3.29 2.44 0.57 45.59 2.99 2.32 0.51 38.23 2.69 2.20 0.46 31.55
FWF04AT
731 4.10 3.08 0.71 65.52 3.78 2.92 0.65 56.67 3.42 2.77 0.59 47.16 3.05 2.62 0.52 38.44
695 3.96 2.93 0.68 61.52 3.65 2.77 0.63 53.21 3.30 2.63 0.57 44.28 2.94 2.49 0.51 36.09
663 3.82 2.80 0.66 57.69 3.52 2.64 0.61 49.90 3.18 2.51 0.55 41.52 2.84 2.37 0.49 33.83
Air temperature (°C DB - °C WB) 27-19
Water temperature (Entering °C - Leaving °C)
6-11 7-12 8-13 9-14
Model
Air Flow
m
3
/hr
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
FWF02AT
663 2.49 2.05 0.43 75.02 2.34 1.97 0.40 67.23 2.09 1.87 0.36 55.24 1.84 1.77 0.32 44.56
630 2.31 1.96 0.40 65.80 2.17 1.88 0.37 59.06 1.94 1.78 0.33 48.70 1.70 1.69 0.29 39.46
595 2.16 1.84 0.37 58.81 2.03 1.76 0.35 52.87 1.81 1.67 0.31 43.74 1.59 1.58 0.27 35.60
FWF03AT
663 4.40 3.19 0.76 77.96 4.10 3.06 0.71 68.15 3.77 2.93 0.65 58.18 3.44 2.79 0.59 49.01
630 4.09 3.02 0.70 68.06 3.81 2.89 0.66 59.53 3.50 2.76 0.60 50.86 3.19 2.64 0.55 42.90
595 3.93 2.82 0.68 63.27 3.66 2.70 0.63 55.37 3.36 2.58 0.58 47.33 3.07 2.47 0.53 39.95
FWF04AT
731 4.57 3.41 0.79 79.30 4.25 3.24 0.73 69.62 3.88 3.09 0.67 59.16 3.52 2.94 0.61 49.49
695 4.41 3.24 0.76 74.45 4.10 3.08 0.71 65.36 3.75 2.94 0.64 55.55 3.39 2.80 0.58 46.47
663 4.25 3.09 0.73 69.81 3.96 2.94 0.68 61.29 3.61 2.80 0.62 52.09 3.27 2.67 0.56 43.57
Air temperature (°C DB - °C WB) 30-22
Water temperature (Entering °C - Leaving °C)
6-11 7-12 8-13 9-14
Model
Air Flow
m
3
/hr
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Total
cooling
capacity
kW
Sensible
cooling
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
FWF02AT
663 3.22 2.22 0.55 118.75 3.04 2.12 0.52 106.67 2.81 2.02 0.48 92.12 2.57 1.92 0.44 78.72
630 2.99 2.12 0.51 103.61 2.82 2.02 0.49 93.15 2.60 1.93 0.45 80.58 2.38 1.83 0.41 68.98
595 2.80 1.98 0.48 92.12 2.64 1.89 0.45 82.91 2.44 1.81 0.42 71.82 2.23 1.72 0.38 61.61
FWF03AT
663 5.97 3.61 1.03 137.44 5.70 3.46 0.98 125.76 5.34 3.33 0.92 110.85 4.98 3.19 0.86 96.88
630 5.55 3.41 0.95 119.81 5.30 3.27 0.91 109.64 4.96 3.14 0.85 96.66 4.62 3.02 0.80 84.51
595 5.33 3.19 0.92 111.27 5.09 3.05 0.88 101.83 4.77 2.94 0.82 89.79 4.44 2.82 0.76 78.52
FWF04AT
731 6.12 3.84 1.05 133.54 5.76 3.69 0.99 119.25 5.37 3.53 0.92 104.97 4.98 3.36 0.86 91.55
695 5.91 3.66 1.02 125.32 5.55 3.51 0.96 111.92 5.18 3.36 0.89 98.52 4.80 3.20 0.83 85.95
663 5.70 3.49 0.98 117.45 5.36 3.35 0.92 104.90 4.99 3.20 0.86 92.36 4.63 3.05 0.80 80.57
Cooling capacities FWF (2 pipe)
