• Fan coil units • Ceiling mounted cassette unit • FWF
1
1
• Fan coil units • Ceiling mounted cassette unit • FWF
4
1 Features
Fan coil un Hydronic Sys FWFFan coil un
• Wide operating range
• Quiet operation with auto-swing comfort
• Easy to install and maintain
• 3 speed fan motor
• Double-intake centrifugal fans
• 4 way air discharge and air swing
• Air suction from underneath
• High power air flow
• Slim front panel and aesthetic design
• Tile size decoration panel
• Removable washable air filter (self-extinguishing class 1)
• Built-in high pressure drain pump (up to 700mm condensate water
can be pumped)
• Wireless controller as standard with decoration panel kit
