Daikin FWF04AT [17/19] Sound data
![Daikin FWF04AT [17/19] Sound data](/views2/1486289/page17/bg11.png)
3
1
8
• Fan coil units • Ceiling mounted cassette unit • FWF
15
• Fan coil units • Ceiling mounted cassette unit • FWF
8 Sound data
8 - 1 Sound power spectrum
FWF (2 PIPE)
1/1 Octave Sound Power Level (dB, reference 1pW)
Overall
(dBA)
Model
Freq
125 250 500 1000 2000 4000 8000
FWF02AT
Hi
54 57 53 49 42 39 31 54
Me
53 55 52 48 41 37 30 53
Lo
52 54 51 46 39 35 28 51
FWF03AT
Hi
55 55 52 48 42 38 30 53
Me
54 54 51 47 41 37 30 52
Lo
54 52 49 46 39 34 28 50
FWF04AT
Hi
56 58 54 51 45 47 34 56
Me
55 57 53 50 43 45 32 55
Lo
54 55 51 48 41 42 28 53
Microphone position: FWF
1.4m below the facia
