• Fan coil units • Ceiling mounted cassette unit • FWF
5
• Fan coil units • Ceiling mounted cassette unit • FWF
2 Specifications
2-1 NOMINAL CAPACITY AND
NOMINAL INPUT
FWF02AT FWF03AT FWF04AT
Power Input High W 51 75 78
Medium W 49 74 75
Low W 46 71 71
Cooling
capacity
Total capacity High kW 2.34 4.10 4.25
Medium kW 2.17 3.81 4.10
Low kW 2.03 3.66 3.95
Sensible
capacity
High kW 1.97 3.06 3.24
Medium kW 1.88 2.89 3.12
Low kW 1.76 2.70 2.90
Heating
capacity (2-
pipe)
High kW 3.22 5.12 5.42
Medium kW 3.07 4.98 5.13
Low kW 2.93 4.68 5.04
2-2 TECHNICAL SPECIFICATIONS FWF02AT FWF03AT FWF04AT
Dimensions Unit Height mm 250 250 250
Width mm 570 570 570
Depth mm 570 570 570
Unit with
packing
Height mm 317 317 317
Width mm 630 630 630
Depth mm 630 630 630
Weight Machine weight kg 22.0 23.0 23.0
Operation weight kg 23.0 24.0 24.0
Gross weight kg 23.0 24.0 24.0
Material Electro-galvanised mild steel (ABS)
Sound level Sound
pressure
High dBA 44 44 47
Medium dBA 43 42 46
Low dBA 42 41 44
Sound power High dBA 54 53 56
Medium dBA 53 52 55
Low dBA 51 50 53
Water flow Cooling l/h 402 705 731
Heating l/h 402 705 731
Water pressure
drop
Cooling kPa 67.3 68.6 68.8
Heating kPa 61.9 70.5 71.2
Fan Type Direct drive turbo fan
Air flow rate High m³/h 662 662 731
Medium m³/h 630 630 695
Low m³/h 594 594 662
Speed 3 steps : high, medium, low
Quantity 1 1 1
Motor Type Induction
Standard heat
exchanger
Rows mm 1 2 2
Stages mm 4*(1) + 6*(1) 4 4
Fin pitch mm 1.59 1.27 1.27
Face area m² 0.24 0.309 0.309
Water volume l 0.56 1.15 1.15
Air filter Washable Sarannet
Insulation material PE
Vibration insulation Rubber Bush (Fan Motor)
Water
connections
Std. heat exchanger inch 3/4
Drain mm 19.05 19.05 19.05
