Daikin FWF04AT [19/19] Hydraulic performance
![Daikin FWF04AT [19/19] Hydraulic performance](/views2/1486289/page19/bg13.png)
3
1
10
• Fan coil units • Ceiling mounted cassette unit • FWF
17
• Fan coil units • Ceiling mounted cassette unit • FWF
10 Hydraulic performance
10 - 1 Water pressure drop curve evaporator
FWF
FWF (2 PIPE) cooling
Water flow Water pressure drop (kPa)
m
3
/hr
FWF02AT FWF03AT FWF04AT
0.1 11.03 4.14 0.11
0.2 22.70 8.46 6.10
0.3 41.19 15.32 14.00
0.4 66.38 24.66 23.80
0.5 98.11 36.43 35.47
0.6 136.24 50.59 48.99
0.7 180.64 67.08 64.34
0.8 85.85 81.50
0.9 106.86 100.45
1.0 130.05 121.17
1.1 155.37 143.64
1.2 167.85
FWF
FWF (2 PIPE) Heating
Water flow
m
3
/hr
Water pressure drop (kPa)
FWF02AT FWF03AT FWF04AT
0.1 10.88 4.05 0.11
0.2 22.29 8.28 6.29
0.3 39.01 14.99 14.45
0.4 61.27 24.13 24.55
0.5 89.30 35.65 36.59
0.6 123.31 49.51 50.54
0.7 163.53 65.65 66.37
0.8 84.02 84.08
0.9 104.58 103.63
1.0 127.27 125.01
1.1 152.06 148.20
1.2 178.88 173.17
