Bosch MCM4100 [17/206] Citrus press 12 fig q

Robert Bosch Hausgeräte GmbH 17

Shredding attachment – coarse (C)

Set rotary switch to high speed for grating:

apples, carrots, cheese, cabbage.

Shredding attachment – fine (D)

Set rotary switch to high speed for grating:

carrots, cheese.

Chipper disc (E)

for slicing French fries (chips) and fruit salad

ingredients.

t~êåáåÖ>

qÜÉ=ÅÜáééÉê=ÇáëÅ=áë=åçí=ëìáí~ÄäÉ=Ñçê=éêçÅÉëëáåÖ=

Ü~êÇ=ÅÜÉÉëÉI=åìíëI=ÜçêëÉê~ÇáëÜ=~åÇ=ëáãáä~ê=

ÑççÇëK

Fig. 

 Attach the bowl (arrow on bowl on dot on

the appliance) and rotate as far as possible

in a clockwise direction.

 Insert drive shaft into the bowl.

Depending on the required use:

 Insert the required insert into the carrier

disc.

Note the form and the location

(Fig.



-5a)!

 Attach the carrier disc to the drive shaft.

or:

 Attach chipper disc to the drive shaft.

Attach lid with pusher (match arrow on lid

to arrow on bowl) and rotate in a clockwise

direction. Lid lug must be located fully

in the slot in the bowl handle.

 Set the rotary switch to the desired setting.

 Fill with contents which are to be sliced

or shredded.

 When adding contents which are to be

sliced or shredded, apply only light pres-

sure to the pusher.

 Remove the pusher and add ingredients

through the feed tube.

 Add long and thin contents using the

pusher.

t~êåáåÖ>

bãéíó=íÜÉ=Äçïä=ÄÉÑçêÉ=áí=ÄÉÅçãÉë=ëç=Ñìää=íÜ~í=

íÜÉ=ëäáÅÉÇ=çê=Öê~íÉÇ=ÅçåíÉåíë=êÉ~ÅÜ=íÜÉ=Å~êêáÉê=

ÇáëÅ=çê=íÜÉ=ÅÜáééÉê=ÇáëÅK

Citrus press (12) Fig. 

for pressing the juice out of citrus fruits,

e.g. oranges, grapefruits, lemons.

 Attach the bowl (arrow on bowl on dot on

the appliance) and rotate as far as possible

in a clockwise direction.

 Insert drive shaft into the bowl.

 Attach the citrus press to the drive shaft

(arrow on citrus press on arrow on the

bowl) and rotate in a clockwise direction.

The lug on the strainer basket must be

located fully in the slot in the bowl handle.

 Attach and press on pressing cone.

 To extract juice from the fruits, set the

rotary switch to low speed and press

the fruit onto the pressing cone.

t~êåáåÖ>

kçíÉ=íÜÉ=äÉîÉä=áå=íÜÉ=ÄçïäK=

j~ñK=èì~åíáíóW=RMM=ãäK=

bãéíó=íÜÉ=Äçïä=ïáíÜçìí=ÇÉä~óK

Juice centrifuge (13) Fig. 

For squeezing the juice out of pip fruits

(e.g. apples, pears), berries, pitted stone fruits,

vegetables (e.g. carrots, tomatoes).

 Attach the bowl (arrow on bowl on dot on

the appliance) and rotate as far as possible

in a clockwise direction.

 Insert drive shaft into the bowl.

 Screw on the grater with the filter basket

as far as possible in a clockwise direction.

 Attach lid for juice centrifuge and rotate

in a clockwise direction. Lid lug must be

located fully in the slot in the bowl handle.

 Turn the rotary switch to a low speed

setting.

 Add fruit or vegetables through the fill tube

and only gently push forward with the

pusher. Cut beforehand if necessary.

 After processing, set the rotary switch

briefly to high speed and leave the appli-

ance running until all the fruit pulp has been

squeezed out.

t~êåáåÖ>

kçíÉ=íÜÉ=äÉîÉä=áå=íÜÉ=ÄçïäK=j~ñáãìã=éêçÅÉëJ

ëáåÖ=èì~åíáíóW=ORM=Ö=Ñêìáí=çê=îÉÖÉí~ÄäÉëK

oáëâ=çÑ=áåàìêó=Ñêçã=ëÜ~êé=Ää~ÇÉë>

aç=åçí=éä~ÅÉ=ÑáåÖÉêë=áå=íÜÉ=ÑÉÉÇ=íìÄÉK=

låäó ìëÉ=íÜÉ=éìëÜÉê=ïÜÉå=~ÇÇáåÖ=ãçêÉ=

áåÖêÉÇáÉåíëK
