GB-27
DSB-B150F
GB
GB-26
DIGITAL SATELLITE RECEIVER
DSB-B150F
4.2 OSD Setting
You can set the OSD transparency, the display time,
Color Scheme and OSD Position.
● Select OSD Transparency level.
The OSD Transparency level from 0 to 100%.
Setting is made with the numeric keys,
/
keys or
PG+/PG- keys.
/
keys : Setting in increment of 1%.
PG+/PG- keys : Setting in increment of 10%.
NNoottee
: This transparency is NOT applied to color scheme with
“User Defined” option.
● Set the display duration of the information(banner) box
displayed in the screen.
The time ranges from 0.5 to 60.0 seconds.
Setting is made with the numeric keys,
/
keys or PG+/PG- keys.
/
keys : Adjusting in increment of 0.5sec.
PG+/PG- keys : Adjusting in increment of 1 sec.
● Set the Color Scheme :
You can change color according to your preference.
(i.e background, text, symbol, line, etc)
/
keys : select the color scheme mode.
Color scheme 1: changes the menu to sky blue color.
Color scheme 2: changes the menu to green color.
Color scheme 3: changes the menu to dark brown color.
User defined: Sets the color according to user preference.
EPG colors: Sets the color in the EPG menu.
NNoottee
: Color scheme 1, 2 and 3 may be changed in the future
by upgrading software.
OPERATING THE RECEIVER
3.2 Change PIN Code
To change the PIN Code, select the second option “Change PIN Code”.
This will take you to the following menu:
In this option, you need to enter the current PIN Code at
the first cursor, and at the second cursor enter the desired
PIN Code.
To confirm, you need to enter the new PIN Code again.
Please remember the PIN Code should be a 4 digit numerical
value.
THE FACTORY PRESET PIN Code : 0 0 0 0.
NNoottee
: If you forget the PIN Code, refer to ‘System information’ part.
Once you change password, please do not forget and keep well.
4. System Setup
This option enables you to change the factory preset
system settings as per your requirements.
4.1 Language Selection
The “Language Selection” option allows the user to select
the desired language of the OSD, Soundtrack, Teletext,
Subtitle or EPG. However, these languages for Soundtrack,
Teletext, Subtitle and EPG depend on broadcasting.
For example, even the language for Subtitle can be selected,
it may not be supported because of no Subtitle on the program.
● To accommodate user from different regions speaking
different languages, OSD languages are available
20 languages.
● To select the desired language menu, press
/
keys to
change language and press OK.
● The OSD Language, Soundtrack, Teletext, Subtitle,
or EPG will vary according to the selected language.
OPERATING THE RECEIVER
MF68-00362A_GB 8/25/05 2:14 PM Page 26
