Operator’s Manual City Ranger 2250 Weed brush

Service and maintenance

3.4 Lubrication / storage

There are four lubricating nipples on the weed brush

Lubricate with EP2 lubricant after 50 hours of operation or

after washing.

Cylinder top. (Picture 1)

Cylinder bottom + carrier/driver. (Picture 2)

Guard xture. (Picture 2)

Storage outside the season:

When the weed brush is to be stored outside the season, it

is recommended to remove any loose paint and to repaint

any damaged areas.

It is recommended that the attachment is greased or

sprayed with protective lubricant.

3.5 Replacing the brush

The brush is changed while the attachment is on the

machine.

1. Place the brush as shown in picture 3 (see section 2.4)

and lock the transport lock.

2. Remove the three nuts. (Picture 4)

3. Change the brush and t the nuts.

Warning!

Make sure no one is under the brush

when the bolts are removed. The brush is

abrasive. Use protective gloves.

A new brush can be ordered from an authorised Egholm

dealer.

Lubricating nipple

Lubricating nipples

Three nuts
