1-8

1-8 | Handling Paper

6. To keep the paper wound when you’re not printing, use one of the roll

paper belts included with your printer.

When you’re not using the roll paper belt, keep it wound around the

end of the spindle.

7. See the next section to load the paper for printing.

roll paper belt

Note

To remove the spindle

(and paper roll) from the

printer, first lift out the left

end and then the right

end.
