Product Specifications
15
Product Specifications
Product Specifications
Category Feature Specification
Main
IP Rating IP65
RF Card
XPS2M: 13.56MHz MIFARE, MIFARE Plus, DESFire/EV1 (CSN), FeliCa, ISO14443A,
ISO15693
Multi-Controller Yes
Capacity
Max. User (1:1) 50,000
Max. User (1:N) 50,000
Max. Text Log 100,000
Interface
TCP/IP Yes
RS-485 1ch Host or Slave (Selectable)
Wiegand 1ch In or Out (Selectable)
TTL Input 2 Inputs
Relay 1 Relay
Relay
Voltage Max. 24VDC
Current Typ. 0.5A, Max. 1.0A
Hardware
CPU 533MHz DSP
Memory 16MB RAM + 16MB Flash
LED Multi-Color
Sound 16-bit Hi-Fi
Operating Temp. -35°C ~ 65°C
Tamper Yes
Power 12VDC
Dimensions (W x H x D mm) 80 x 120 x 11.4
Certification CE, FCC, KC, RoHS, REACH
