Thank you for purchasing the Clarion NX504E or FX504E.
●
Please read this owner’s manual thoroughly before operating this equipment.
●
After reading this manual, be sure to keep it on hand for future reference.
●
Check the contents of the enclosed warranty card and keep it carefully with this manual.
●
The provided disc (CD-ROM manual) cannot be played back on this unit.
In particular, read the descriptions in “To Ensure Safe Use.” This describes cautions
to ensure safe use of the unit without inflicting harm or damage on yourself or
others.
P. 3
●
The content of this manual may differ in part with that of the actual product due to
modifications, etc. to the specifications.
●
The content of this manual may be changed in part without notice.
When transferring or reselling the unit or disposing of it, delete (initialize) all data
saved on it to protect your personal information and copyright protection.
Meanings of Symbols Used in This Manual
WARNING
Preparations
This indicates the possibility that failure to
follow this instruction might lead to death
or serious injury.
This explains what must be done
beforehand to operate the product.
CAUTION
Notice
This explains things that may cause injury
if instructions are not followed.
This explains limitations related to
operations.
Attention MEMO:
Though this does not fall under the
category of “WARNING” or “CAUTION”,
this indicates that there is the danger of
money or time being lost.
This explains supplementary information
for mastering use of the unit.
CAUTIONS:
This appliance contains a laser system
and is classified as a “CLASS 1 LASER
PRODUCT”.
To use this model properly, read this Owner’s
Manual carefully and keep this manual for
your future reference. In case of any trouble
with this player, please contact your nearest
“AUTHORIZED service station”. To prevent
direct exposure to the laser beam, do not
try to open the enclosure.
!CAUTION
USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED IN THE
OWNER’S MANUAL MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
ADVARSEL.
Denne mærking er anbragt udvendigt på
apparatet og indikerer, at apparatet arbejder
med laserstråler af klasse 1, hvilket betyder,
at der anvendes laserstråler af svageste
klasse, og at man ikke på apparatets
yderside kan blive udsat for utilladelig
kraftig stråling.
APPARATET BØR KUN ÅBNES AF
FAGFOLK MED SÆRLIGT KENDSKAB TIL
APPARATER MED LASERSTRÅLER!
Indvendigt i apparatet er anbragt den
her gengivne advarselsmækning, som
advarer imod at foretage sådanne indgreb
i apparatet, at man kan komme til at
udsaætte sig for laserstråling.
OBS!
Apparaten innehåller laserkomponenten
som avger laserstrålning överstigande
gränsen för laserklass 1.
VAROITUS
Suojakoteloa si saa avata. Laite sisältää
laserdiodin, joka lähettää näkymätöntä
silmille vaarallista lasersäteilyä.
NX504E
FX504E
