30 NX504E/FX504E
English
Entering a number to make a
call
Attention
•Whileyouaredriving,youcannotenter
telephonenumberstomakeacall.Always
stopatasafelocationbeforemakinga
telephonecall.
Notice
•Alwaysinputtheareacodewhencallinga
land-linephone.
•Withsomecellphones,youmaynotbe
abletoredialimmediatelyafterhanging
upacallyoudialed.Waitawhilebefore
dialingthenumberagain.
1
MENU
Phone
2
Enter the telephone number.
3
The telephone number is dialed and
the other party is called.
:
The call is stopped if this is
touched while you are calling the
other party.
4
To end a telephone call
This disconnects the call and returns
you to the screen before you made
the call.
The telephone number you called,
name (when registered to the
phonebook) and dial date/time are
saved as the outgoing calls log. Only
the latest call log is shown for the
same phone numbers.
Making calls from the outgoing/
incoming calls log
Notice
•Youcannotmakecallsfromtheincoming
callslogwhentheincomingcallwasfrom
awithheldnumber.
1
MENU
Phone
2
3
or
4
Select the other party you want
to dial.
5
Call
The registered telephone number is
dialed and the call is made.
MEMO:
•Thelatesttencallsrecordedontheunit
aredisplayedintheincoming/outgoing
callslog.
•Inthecaseoftelephonenumbers
registeredtothephonebook,the
registerednamesaredisplayed.
Deleting the incoming/outgoing
calls log
1
MENU
Phone
2
3
or
4
Delete All
5
OK
The entire outgoing call log or
incoming call log is deleted.
Registering a phonebook
You can register the phonebook on a
cellphone in advance to the unit, and make
calls from there.
To register the phonebook on a cellphone,
use the phonebook download function
on the cellphone. With some cellphones,
phonebooks cannot be downloaded.
For details, refer to the User’s Manual for
the cellphone.
MEMO:
•Afteraphonebookisdownloaded,the
cellphoneconnectionissometimes
disconnected.Ifthishappens,selectthe
cellphoneyouwanttoconnecttoagain
fromthetelephoneselectionscreen.
1
MENU
Phone
2
3
Download Phonebook
MEMO:
•Ifphonebookdatahasalreadybeen
registered, Download memory is
displayed.
4
Select the download method.
Download Phonebook:
This downloads the phonebook
data from a Bluetooth-compatible
cellphone and overwrites and
saves the phonebook data on the
unit.
Note that the previous downloaded
data is overwritten and can no
longer be used.
Download 1 Entry:
This downloads the phonebook
data from a Bluetooth-compatible
cellphone and adds and saves
this data to the phonebook data
on the unit. Note that the previous
downloaded data is not overwritten
and can still be used.
Cancel:
This cancels the download and
returns you to the previous screen.
5
Download the phonebook from a
cellphone.
The phonebook of the currently
selected cellphone is downloaded to
the unit.
