52 NX504E/FX504E
English
iPhone, iPod, iPod classic, iPod nano,
iPod touch, and iTunes are trademarks
of Apple Inc., registered in the U.S. and
other countries.
Lightning is a trademark of Apple Inc.
●
DivX
®
, DivX Certified
®
and associated
logos are trademarks of Rovi Corporation
or its subsidiaries and are used under
license.
DivX Certified
®
to play DivX
®
video,
including premium content.
Covered by one or more of the following
U.S. patents:7,295,673; 7,460,668;
7,515,710; 7,519,274
ABOUT DIVX VIDEO: DivX
®
is a digital
video format created by DivX, LLC, a
subsidiary of Rovi Corporation.
This is an official DivX Certified
®
device
that has passed rigorous testing to verify
that it plays DivX video.
Visit divx.com for more information and
software tools to convert your files into
DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This
DivX Certified
®
device must be registered
in order to play purchased DivX Video-
on-Demand (VOD) movies. To obtain
your registration code, locate the DivX
VOD section in your device setup menu.
Go to vod.divx.com for more information
on how to complete your registration.
(NX504E Only)
●
The Bluetooth
®
word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by Clarion Co., Ltd, is under
license.
●
The terms HDMI and HDMI High-
Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered
trademarks of HDMI Licensing LLC in the
United States and other countries.
●
Android is the trademark of Google Inc.
●
How to get source code that is
considered open source.
This unit uses open source software.
If you want to get this software’s source
code, you can download it from our
website.
Refer to the following website about
getting the source code.
http://www.clarion.com/xe/en/open-
source/index.html
Disposal, transfer and
resale of this product
The following describes the cautions when
reselling or transferring the unit to a third
party or disposing of it.
Deletion of data from the unit
When reselling or transferring the unit to
a third party or disposing of it, please pay
attention to the following points and please
delete all data at your own responsibility.
❏
To protect your privacy...
Initialize (delete) all data including individual
information saved to memory by following
the procedure below.
❏
To protect copyright...
Initialize (delete) the data saved in memory
by following the procedure below. There is
the risk that copyrighted data might infringe
on copyright laws if the unit is transferred (for
a charge or free of charge) or resold with
data still left on it without the consent of the
copyright holder.
✽
Clarion bears no responsibility for damages
to the customer due to leakage of leftover
data, the customer is responsible for
managing data appropriately as described
above.
Deleting data (initializing)
Delete (initialize) all data saved on the unit.
1
MENU
2
Restore
at [Reset to Factory
Setting]
The confirmation screen is displayed.
3
OK
This clears all data saved on the unit.
MEMO:
•Dataafterupdatesissaved,initializationis
notdonetoprogramsthatareupdated.
