TASCAM CD-9010CF
11
2 – Names and Functions of Parts
This button lights during monitoring playback.
r PLAY button/indicator
Press when playback is stopped or in standby to start
playback. This button lights during playback or when in
playback standby.
When the ON LINE button on a connected TASCAM
RC-9010/RC-9010S remote control (sold separately) is
lit, or the
SYSTEM
menu
ONLINE FUNCTION
item is set to
AlwaysON
, online playback occurs and the playback signal is
output through the LINE OUTPUTS (R/L) and the DIGITAL
OUTPUT.
To send the signal through the MONITOR OUTPUTS (R/L)
and PHONES jack, set the
SYSTEM
menu
MON MUTE ONLINE
item to
OFF
. (See "Muting monitoring when online" on page
45.)
This button lights during online playback.
t STANDBY button/indicator
When playback is stopped or during jog playback, press this
button to pause and start playback standby at the current
point.
When in monitoring playback mode and
MONITOR PLAY STBY
is set to
BACK CUE
in the
PLAY
menu, press this button
to return to the point at which monitoring playback last
started and enter standby. When
MONITOR PLAY STBY
is set
to
NORMAL
, press to enter playback standby at the current
point.
When using online playback, pressing this button has a
different function depending on the playback mode.
Playback mode Function
CONTINUE
or
SINGLE
When
ONLINE PLAY STBY
is set to
NOR-
MAL
in the
PLAY
menu, enter playback
standby at the current position.
When set to
BACK CUE
, locate to the last
cue point and enter playback standby.
PROGRAM
When
ONLINE PLAY STBY
is set to
NOR-
MAL
in the
PLAY
menu, enter playback
standby at the beginning of the next
track.
When set to
BACK CUE
, locate to the last
cue point and enter playback standby.
This button lights when in playback standby.
y TRACK .// buttons
Use these buttons to skip between and select tracks.
u SEARCH m/, buttons
Search while pressing these buttons.
While pressing the SEARCH , (or SEARCH m) button
to search, you can change the search speed by pressing the
other SEARCH m/, button.
i Display
This shows disc information, the operation mode, menus
and other data.
o PLAY MODE button
When the Home Screen is open, press this button to cycle
through the playback modes in the following order.
CONTINUE mode
SINGLE mode
PROGRAM mode
p HOME button
When the
MENU
screen,
BROWSE
screen,
PROGRAM
screen or
CUE LIST
screen is open, press this to return to the Home
Screen.
Press this button when the Home Screen is open to scroll
CD-TEXT file names and data in the information area of the
Home Screen.
Press the MENU button while pressing and holding this
button to turn the panel lock function ON and OFF. (See
"Setting the panel lock function" on page 20.)
When the Home Screen is open, press and hold this button
while turning the DATA dial to adjust the brightness of the
display and the indicators.
You can adjust the brightness of the display alone by
pressing and turning the DATA dial while pressing and
holding this button.
NOTE
This operation only adjusts the contrast of the display and
indicators of this unit. It does not adjust the contrast of a
connected TASCAM RC-9010/RC-9010S remote control (sold
separately).
a MENU button
Press to open the
MENU
screen.
Press this button while pressing and holding the HOME
button to turn the panel lock function ON and OFF. (See
"Setting the panel lock function" on page 20.)
s DATA dial
Turn the DATA dial to select items on the
MENU
screen.
Press the dial to use it as an ENTER button when confirming
operations on the
MENU
screen.
When the Home Screen is open, press and hold the HOME
button while turning the dial to adjust the brightness of the
display and the indicators.
To adjust the brightness of the display alone, press and turn
this dial while pressing and holding the HOME button.
Press and hold the TIME DISPLAY button while turning the
DATA dial to adjust the display contrast.
NOTE
These operations only adjust the brightness and contrast of
the display and indicators of this unit. They do not adjust the
brightness and contrast of a connected TASCAM RC-9010/
RC-9010S remote control (sold separately).
