20
TASCAM CD-9010CF
3 – Preparations
Connecting headphones
Connect stereo headphones to the PHONES jack on the front
panel. Use the PHONES knob to adjust the headphones output
level.
CAUTION
Before connecting headphones, use the PHONES knob to lower
the volume. Failure to do so might result in sudden loud sounds,
which could harm your hearing or result in other trouble.
NOTE
The PHONES knob can be pushed in to prevent the level from
being accidentally changed. The knob can be used when out.
The PHONES knob when pushed in
The PHONES knob when out
Setting the panel lock function
The unit can be set so that it can only be operated using a
TASCAM RC-9010/RC-9010S remote control (sold separately).
1. Press the MENU button to open the
MENU
screen.
2. Open the
REMOTE
menu screen.
3. Select
OPERATION PANEL
.
4. Press the DATA dial to move the cursor (selected area)
right to select the setting.
5. Turn the DATA dial to set whether or not you can use the
front panel controls to control the unit.
•
CD+RC
: The unit can be controlled using a TASCAM RC-
9010/RC-9010S remote control (sold separately) and
the unit's front panel buttons.
•
RC ONLY
(default value): When a TASCAM RC-9010/RC-
9010S remote control (sold separately) is connected,
the unit's front panel buttons (other than the OPEN/
CLOSE, CD/CF and ST/MONO buttons) are disabled.
6. After completing the setting, press the HOME button to
return to the Home Screen.
NOTE
When a remote is not connected, even when this item is set
•
to RC ONLY, the panel controls will not lock.
To unlock the panel, press the MENU button, while pressing
•
and holding the HOME button. When the “OPERATION PA
NEL Change to CD+RC?” pop-up message appears, select
“Yes” to unlock the panel.
You can also lock the panel controls by pressing the MENU
•
button while pressing and holding the HOME button. When
the pop-up message appears, select “Yes”.
The panel lock function setting is stored even when the
•
power is turned OFF.
