TASCAM CD-9010CF
51
11 – Message list
Error messages
If one of the following error messages appears in a pop-up, press the DATA dial to close the message. Then try to resolve the issue. If you
are still unable to correct the problem, please contact the dealer from which you purchased the unit or a TASCAM service center (see the
back cover of this manual).
1st line 2nd line Meaning
1
- error - DECODE
Failed to play WAV file.
2
- error - MIX DISC
The disc has both WAV format files and audio CD format files on it.
3
- error - MEMORY READ
Ripping cannot be executed because media is not loaded in the selected device.
4
- error - TRACK
Playback is not possible because the file on the CD is of an unplayable format.
5
- error - CF WRITE
Failed to write to the CF card.
Warning messages
When an operation cannot be conducted, one of the following pop-up warning messages will appear on the display. After appearing for
about two seconds, warning messages automatically disappear.
1st line 2nd line Meaning
1
- caution - MEDIA FULL
Ripping is not possible because the media does not have enough open space.
2
- caution - TRACK FULL
Ripping is not possible because the maximum number of tracks (999) has been reached.
3
- caution - NOT EXECUTE
Failed to execute the editing operation.
4
- caution - CAN'T EDIT
Editing was not possible due to system limitations.
5
- caution - CAN'T SELECT
Selection/execution was not possible due to system limitations.
6
- caution - TRK PROTECT
Editing was not possible because the track is protected.
7
- caution - NAME FULL
The maximum number of characters for the name (text field) has been reached.
8
- caution - PROGRAM FULL
The track cannot be added because the maximum number of tracks in a program has been
reached.
9
- caution - SAME NAME
An item with the same name already exists.
Operation messages
As necessary, the following messages will appear in the time display area.
1st line Meaning
1
CLOSE
The disc tray is closed.
2
DEVICE ERROR
The device cannot be detected. Please contact TASCAM customer support.
3
MEDIA ERROR
The media is not playback media.
4
MEDIA READING
Now reading from media.
5
NO MEDIA
Media is not loaded in the current device.
6
OPEN
The disc tray is open.
7
POWER ON
The system is starting up and initializing.
8
RIPPING
The CD contents are being converted and copied to the CF card.
9
UNKNOWN
The media is in a format other than FAT. Format the media with the unit in order to use them
together.
The disc is an incompatible format (DVD, non-hybrid SACD, etc.). Use an audio CD, or data CD with
WAV files.
