22
TASCAM CD-9010CF
4 – Playback
Playing a track once from the beginning
Follow these steps to select and check the desired track
(monitoring playback), and then play it through the main
outputs (online playback). These procedures assume that all
menu items are at their default settings.
1. Press the PLAY MODE button to select single mode.
Press the
•
PLAY MODE button as many times as
necessary until the
SINGLE
playback mode indicator
appears on the Home Screen.
2. Press the MENU button to open the
MENU
screen, and set
AUTO CUE
in the
PLAY
menu to
ON
.
3. Press the HOME button to open the Home Screen.
4. Use the TRACK .// buttons to select a track for
playback.
The unit enters playback standby at the position where
•
an audio signal is detected in the selected track (and
the STANDBY button lights).
NOTE
When the playback mode is set to CONTINUE or SINGLE, you can
use the number buttons (0 through 9) to select tracks. Enter two
digits for audio CDs or three digits for data CDs or CF cards. (For
example, press the 0 button followed by the 2 button to select
track 2 on an audio CD.)
5. To check the playback signal, press the MONITOR button
to start monitoring playback (the MONITOR button
lights).
In addition to using an external monitoring system, you
•
can also monitor the playback signal using headphones
connected to the unit's PHONES jack.
6. After checking the signal, press the STANDBY button.
The playback position is set to the point where the
•
track starts and the unit enters playback standby mode
(the STANDBY button lights).
7. Press the PLAY button to start online playback.
When the track ends, the unit re-enters playback
•
standby.
Press the STOP button to stop playback immediately.
•
Playing a track from the middle
Follow these steps to find a point in the middle of a track and
start playback from the main outputs from that point.
1. When stopped or during playback standby, you can
search within a track using the SEARCH m/, buttons
to locate a desired point and put the unit in playback
standby there. (See "Searching within tracks" on page 23.)
2. At the desired playback point, press the MONITOR button
to start monitoring playback and check it.
3. After checking, press the STANDBY button to return to
the point set earlier and start online playback standby
(STANDBY button lights).
To adjust the set point, return to step 1.
•
4. Press the PLAY button to start online playback.
When the track ends, the unit will enter playback standby
mode.
NOTE
Press the STOP button to stop playback immediately.
Automatic cue point memory (last cue)
When you start monitoring playback from a stopped or playback
standby state, the starting position is automatically memorized
as a cue point.
The most recently added cue point is the "last cue point". Press
the STANDBY button to locate to the last cue point (where
monitoring playback last started) and enter playback standby.
NOTE
When using a TASCAM RC-9010/RC-9010S remote control
•
(sold separately), you can assign automatic cue points to
the number (0–9) buttons.
In jog mode, pressing the
•
STANDBY button saves the
current position as a cue point.
