TASCAM DP-24SD
41
6 - Basic Recording
4. Set canceling (undo) operations.
LEVEL 1 (Default)
HISTORY LIST
is not displayed when you press the
UNDO/REDO button. In other words, this returns the unit
to the state before the last operation (single operation). (To
cancel the undo, perform REDO.)
LEVEL 10
When you press the UNDO/REDO button,
HISTORY
LIST
appears and you can return to the state before up to
10 past operations.
NOTE
Even when you change from
LEVEL10
to
LEVEL1
, the
history for a maximum of 10 actions remains stored. The
position of the cursor on the list shows the current position.
Undoing the last operation (single undo)
Press the UNDO/REDO button to return to the state before the
last operation.
After doing this, the UNDO/REDO button lights, showing that
redo (see below) is possible.
8
Canceling an undo operation (redo)
Press the UNDO/REDO button when it is lit.
The last action is enabled again, the unit returns to its newest
state, and the UNDO/REDO button becomes unlit.
Undoing older operations (multiple undo)
To perform the multi-undo, first you must set
Undo
History
on the
PREFERENCE
menu to
LEVEL10
. (See
“Undo feature settings” on page 40.)
1. Set
Undo History
on the
PREFERENCE
menu to
LEVEL10
.
2. When the Home screen is displayed, press the UNDO/REDO
button to display
HISTORY LIST
.
The maximum number for the undo history is 10. In other words,
a maximum of 10 operations can be undone.
This operation is called "multi-undo" because it allows you
to undo multiple events and return to an earlier state.
3. Use the JOG/DATA dial to select (blue highlight) the event
that you want to return to (all events after the selected event
will be undone).
4. Press the F4 (t) button.
The multi-undo is performed and the song is restored to the
state just after the selected event was performed.
In this state, the UNDO/REDO button lights.
The event information undone through the above operation
is not erased. The unit has simply been returned to a
previous state.
On the
HISTORY LIST
screen, 0 icon appears next to
the last event after undoing. When the most recent event is
selected on
HISTORY LIST
, pressing the F4 (t) button
returns to the most recent operation.
CAUTION
•
When saving a song, a maximum of 10 operation history
events can be saved with the song data. If the number of
operation history events exceeds 10, the oldest events in the
history are erased. These erased events cannot be restored.
•
Since the history information is stored as the song infor-
mation, even when the power is turned off (standby), the
previous operation remains stored, so the undo operation is
also possible next time the power is turned on.
•
If you perform an operation that is added to the history
when the UNDO/REDO button is lit after a multi-undo
operation has been performed, the history after the
multi-undo will be erased.
