TASCAM DP-24SD
9
1 – Introduction
Trademarks
• TASCAM and PORTASTUDIO are trademarks of TEAC
Corporation, registered in the U.S. and other countries.
• SDHC Logo is a trademark of SD-3C, LLC.
• Windows, Windows XP, Windows Vista, Windows 7 and
Windows 8 are either registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other
countries.
• iMac, Mac OS and OS X are trademarks of Apple Inc.
• Pentium and Intel are trademarks of Intel Corporation in the
U.S. and/or other countries.
• Other company names, product names and logos in this
document are the trademarks or registered trademarks of
their respective owners.
Any data, including, but not limited to information,
described herein are intended only as illustrations of such
data and/or information and not as the specifications for
such data and/or information. TEAC Corporation disclaims
any warranty that any use of such data and/or information
shall be free from infringement of any third party's intel-
lectual property rights or other proprietary rights, and
further, assumes no liability of whatsoever nature in the
event of any such infringement, or arising from or connected
with or related to the use of such data and/or information.
This product is designed to help you record and reproduce
sound works to which you own the copyright, or where you
have obtained permission from the copyright holder or the
rightful licensor. Please use the product appropriately.
Under no circumstances will TEAC Corporation be respon-
sible for the consequences of any illegal copying performed
using the recorder.
Precautions for placement and use
• The operating temperature should be between 5°C and
35°C (41°F and 95°F).
• Do not install in the following types of places. Doing
so could degrade the sound quality and/or cause
malfunctions.
Places with significant vibrations or that are otherwise
unstable
Near windows or other places exposed to direct sunlight
Near heaters or other extremely hot places
Extremely cold places
Places with bad ventilation or high humidity
Very dusty locations
• Make sure that the unit is mounted in a level position for
correct operation.
• Do not place any object on the unit for heat dissipation.
• Avoid installing this unit on top of any heat-generating
electrical device such as a power amplifier.
Beware of condensation
If the unit is moved from a cold to a warm place, or used after a
sudden temperature change, there is a danger of condensation;
vapor in the air could condense on the internal mechanism,
making correct operation impossible. To prevent this, or if this
occurs, let the unit sit for one or two hours at the new room
temperature before using.
Cleaning the unit
To clean the unit, wipe it gently with a soft dry cloth. Do not
wipe the unit with chemical cleaning cloths, paint thinner,
alcohol or other chemical agents because they could damage its
surface or cause discoloration.
About SD cards
This unit uses SD cards for recording and playback.
SD and SDHC cards that are at least 512 MB in size can be used.
A list of SD cards that have been confirmed for use with this unit
can be found on our web site. Please access to a product page of
this product from the TEAC Global Site (http://teac-global.com)
to find the list or contact the TASCAM customer support service.
Precautions for use
SD cards are delicate media. In order to avoid damaging a card
or the card slot, please take the following precautions when
handling them.
• Do not leave them in extremely hot or cold places.
• Do not leave them in extremely humid places.
• Do not let them get wet.
• Do not put things on top of them or twist them.
• Do not hit them.
• Do not remove or insert an SD card when the power is ON.
Using the TEAC Global Site
You can download updates for this unit from the TEAC Global Site:
http://teac-global.com/
In the TASCAM Downloads section, select the desired language
to open the Downloads website page for that language.
Product registration
Customers in the USA, please visit the following TASCAM
website to register your TASCAM product online.
http://tascam.com/
