TASCAM US-20x20
13
5 – Connections
Guitar
When connecting a guitar or bass guitar directly to this unit, use
the IN1 or IN2 jack on the front of the unit.
Electronic devices and other audio
equipment
Connect electronic instruments and other audio equipment
to the IN3–IN8 jacks on the front of the unit and the IN9–
IN10 jacks on the back of the unit. Set the LEVEL switch for
the the IN9–IN10 jacks to −10dBV when connecting unbal-
anced equipment and to +4dBu when connecting balanced
equipment.
Analog record players
The output of an analog record player cannot be connected
directly to this unit. To connect an analog record player to this
unit, a phono amp and equalizer (or an audio amplifier that has
phono input jacks) must be connected between them.
Monitor speakers
Connect monitor speakers (powered speakers or an amplifier
and speaker system) to the LINE OUT 1-2 jacks on the back of
the unit.
Use the LINE OUT 1-2 knob on the front of the unit to adjust the
speaker volume.
Headphones
Connect headphones to the PHONES 1 and PHONES 2 jacks
(standard stereo) on the front of the unit.
CAUTION
Before connecting headphones, minimize the volumes with
the PHONES 1 and PHONES 2 knobs. Failure to do so might
cause sudden loud noises, which could harm your hearing
or result in other trouble.
MIDI connections
Connect sound modules, keyboards, synthesizers, drum
machines and other MIDI devices to the unit in the following
manner.
•
If you want to monitor sound from a MIDI device, connect
its outputs to the IN1–IN8 jacks on the front of the unit or
the IN9–IN10 jacks on the back of the unit. You could also
use an external mixer for monitoring.
•
You can also use the MIDI IN and MIDI OUT connectors
on the back of the unit to send and receive MIDI timecode
(MTC). By doing this, you can use an application that
supports MTC to synchronize a multitrack recorder (MTR)
and MIDI devices.
CAUTION
When using Windows Media Player, if the “Sound and Audio
Devices Properties” Control Panel “MIDI music playback
(default device)” is set to “Microsoft GS Wavetable SW
Synth", you will not be able to hear MIDI performances
through this unit's LINE OUT 1–10, PHONES 1, PHONES 2,
COAXIAL OUT and OPTICAL (S/MUX) OUT connectors.
Connecting with iOS devices
You can use a Lightning to USB Camera Adapter* to connect the
unit to an iOS device and use it as an interface with that device.
* *You will need to prepare an Apple genuine Lightning to USB
Camera Adapter (sold separately).
NOTE
•
When connected, this unit will not provide power to the iOS
device.
•
iOS does not support 176.4/192kHz sampling frequencies.
