TASCAM US-20x20
3
1 – Introduction
Features
•
Ultra-HDDA (High Definition Discrete Architecture) mic
preamps with −125dBu EIN
•
8 Ultra-HDDA mic preamps, 8 XLR/TRS inputs and 2 TRS
input jacks
•
Three switchable modes: interface, mic preamp, mixer
•
Support for high-resolution recording formats up to
24-bit/192kHz
•
Supports Windows and Mac
•
Connect with computers using USB 3.0 (Windows 10 only)
•
Connect with iOS devices including iPad
•
Can provide +48V phantom power
•
Supports direct guitar input.
•
Input level specifications boast a 56dB range and support
dynamic mic input
•
Tough metal casing can endure even hard use
•
Angled design provides excellent usability on a desktop
•
Two 70mW+70mW standard TRS headphone output jacks
•
Separate controls for line and headphone output volumes
•
MIDI input and output enable connection with keyboards
and other MIDI devices
•
Low latency monitoring through the DSP mixer
•
DSP mixer with 4-band EQ and compression on each input
channel (usable in interface and mixer modes)
•
Patch bay allows outputs to be assigned freely (usable in
interface and mixer modes)
•
Ten scene memories (can be renamed) for saving DSP mixer
settings
•
Ten analog TRS output jacks
•
S/PDIF COAXIAL digital input and output jacks
•
TOSLINK multichannel optical digital input and output
connectors (support SMUX2/SMUX4)
•
BNC word clock input and output connectors
•
Supports USB Audio Class 2.0
•
Operation confirmed with major DAW software, including
Sonar, ProTools, Cubase, Live, Studio One and GarageBand
•
Product compliant with RoHS
•
Rack mount adapters and hex key included
•
AC adapter included
8
Note about computer operation
If you are unsure about anything related to the basic operation
of a computer when it is mentioned in an explanation in this
manual, please refer to the computer operation manual.
Conventions used in this manual
In this manual, we use the following conventions:
•
Switches, connectors and other physical parts of this unit
are written using a bold font like this: PHONES knob.
•
Information shown on a computer display is written like
this: “OK”.
•
As necessary, additional information is provided under TIP,
NOTE and CAUTION headings.
TIP
These are tips about how to use the unit.
NOTE
These provide additional explanations and describe special
cases.
CAUTION
Failure to follow these instructions could result in injury,
damage to equipment or lost recording data, for example.
