Fluke 743B [113/134] Dc voltage measurement

Documenting Process Calibrator

Specifications

103

DC Voltage Measurement

Range Resolution

Models 741B and 743B

% of Reading +% of Full Scale

1 Year 2 Year

110 mV 1 µV 0.025% + 0.015% 0.05% + 0.015%

1.1V 10 µV 0.025% + 0.005% 0.05% + 0.005%

11V 100 µV 0.025% + 0.005% 0.05% + 0.005%

110V 1 mV 0.05% + 0.005% 0.1% + 0.005%

300V 10 mV 0.05% + 0.005% 0.1% + 0.005%

Temperature Coefficient: (0.001% of rdg. + 0.0015% f.s.)/°C in the ranges -10 to 18°C and 28 to 50°C

Input Impedance: 5 MΩ

Common Mode Error: 0.008% f.s./(Common Mode Volt)

Maximum Input Voltage: 300V rms
