741B/743B

Users Manual

118

Top and Bottom Limits of Ranges with Auto Range On (cont.)

Range, Current Measure

22 mA +22.000 mA 0.000 mA

110 mA +110.00 mA +30.00 mA

Range, Current Source

22 mA +30.000 mA 0.000 mA

Range, Frequency Measure

100 Hz 109.99 Hz 1.00 Hz

1 kHz 1099.9 Hz 100.00 Hz

10 kHz 10.999 kHz 1.000 kHz

50 kHz 50.00 kHz 10.00 kHz
