Fluke 743B [124/134] Temperature resistance temperature detectors

741B/743B

Users Manual

114

Temperature, Resistance Temperature Detectors

Temperature, RTDs, Model 741B and 743B

Type (α) Range °C

Measure °C Source °C

1 Year 2 Year 1 Year 2 Year

100Ω Pt(3926) -200 to 0 0.3 0.4 0.1 0.2

0 to 630 0.5 0.8 0.2 0.4

100Ω Pt(385) -200 to 0 0.3 0.5 0.1 0.2

0 to 400 0.5 0.8 0.2 0.4

400 to 800 0.8 1.0 0.4 0.5

120Ω Ni(672) -200 to 260 0.3 0.4 0.1 0.2

200Ω Pt(385) -200 to 0 0.3 0.5 0.1 0.2

0 to 400 0.5 0.8 0.2 0.4

400 to 630 0.8 1.0 0.4 0.5

500Ω Pt(385) -200 to 0 0.3 0.5 0.1 0.2

0 to 400 0.5 0.8 0.2 0.4

400 to 630 0.8 1.0 0.4 0.5
