Fluke 743B [119/134] Resistance sourcing

Documenting Process Calibrator

Specifications

109

Resistance Sourcing

Range Resolution

Models 741B and 743B

% of Output + ohms

1 Year 2 Year

11.000Ω 1 mΩ 0.01% + 0.02 0.02% + 0.02

110.00Ω 10 mΩ 0.01% + 0.04 0.02% + 0.04

1.1000 kΩ 100 mΩ 0.02% + 0. 5 0.03% + 0.5

11.000 kΩ 1Ω 0.03% + 5 0.04% + 5

Temperature Coefficient: (0.01% of f.s.)/°C in the ranges -10 to 18°C and 28 to 50°C

Maximum and Minimum Current through Source Resistance:

11Ω Range: 3 mA dc max, 0.1 mA dc min

110Ω Range: 3 mA dc max, 0.1 mA dc min

1.1 kΩ Range: 3 mA dc max, 0.01 mA dc min

11 kΩ Range: 1 mA dc max, 0.01 mA dc min

Common Mode Error: 0.008% f.s/(Common Mode Volt)

Maximum Input Voltage: 30V dc
