14
Feedback from the Drive – EFB
Feedback from the Drive – EFB
Pre-defined Feedback
Inputs to the controller (drive outputs) have pre-defined meanings established by the
protocol. This feedback does not require drive configuration. The following table lists
a sample of feedback data. For a complete listing, see input word/point/object
listings in the technical data for the appropriate protocol starting on page 19.
Note! With Modbus, any parameter can be accessed using the format: 4 followed by
the parameter number.
Mailbox Read/Write
The ACH550 provides a “Mailbox” function to access parameters that have not been
pre-defined by the protocol. Using mailbox, any drive parameter can be identified
and read. Mailbox can also be used to adjust parameter settings by writing a value to
any parameter identified. The following table describes the use of this function.
1. As noted above, Modbus provides direct access to all parameters using the format: 4 followed by
the parameter number.
Drive Parameter
Protocol Reference
Modbus N2 FLN
0102 SPEED 40102 AI3 5
0103 FREQ OUTPUT 40103 AI1 2
0104 CURRENT 40104 AI4 6
0105 TORQUE 40105 AI5 7
0106 POWER 40106 AI6 8
0107 DC BUS VOLT 40107 AI11 13
0109 OUTPUT VOLTAGE 40109 AI12 14
0115 KWH COUNTER 40115 AI8 10
0118 DI1-3 STATUS – bit 1 (DI3) 40118 BI12 72
0122 RO1-3 STATUS 40122 BI4, BI5, BI6 76, 77, 78
0301 FB STATUS WORD – bit 0 (STOP) 40301 bit 0 BI1 23
0301 FB STATUS WORD – bit 2 (REV) 40301 bit 2 BI2 21
Name Description
Protocol Reference
Modbus
1
N2 FLN
Mailbox
Parameter
Enter the number of the drive parameter to access. Does not
apply.
AO19 95
Mailbox
Data
Contains the parameter value after a read, or enter the
desired parameter value for a write.
AO20 96
Mailbox
Read
A binary value triggers a read – the value of the “Mailbox
Parameter” appears in “Mailbox data”.
BO19 97
Mailbox
Write
A binary value triggers a write – the drive value for the
“Mailbox Parameter” changes to the value in “Mailbox data”.
BO20 98
