8
Communication Set-up – EFB
Note! After any changes to the communication settings, protocol must be
reactivated by either cycling the drive power, or by clearing and then restoring the
station Id (5302).
5304 EFB PARITY
Defines the data length, parity
and stop bits to be used with
the RS485 link communication.
• The same settings must be
used in all on-line stations.
0 = 8
N1 – 8 data bits, No parity,
one stop bit.
1 = 8
N2 – 8 data bits, No parity,
two stop bits.
2 = 8
E1 – 8 data bits, Even
parity, one stop bit.
3 = 8
O1 – 8 data bits, Odd
parity, one stop bit.
When this
protocol is
selected, the
default value for
this parameter
is: 1
When this protocol is selected, the
default value for this parameter is: 0
5305 EFB CTRL PROFILE
Selects the communication
profile used by the EFB
protocol.
0 =
ABB DRV LIM – Operation of
Control/Status Words
conform to ABB Drives
Profile, as used in ACH400.
1 =
DCU PROFILE – Operation of
Control/Status Words
conform to 32-bit DCU
Profile.
2 =
ABB DRV FULL – Operation
of Control/Status Words
conform to ABB Drives
Profile, as used in ACH600/
800.
When this
protocol is
selected, the
default value for
this parameter
is: 0
N/A. When this protocol is selected,
the default value for this parameter
is: 0.
Changing the value for this parameter
has no effect on this protocol’s
behavior.
5310 EFB PAR10 Not used for
Comm setup.
Sets them response turnaround time in
milliseconds. When this protocol is
selected, the default value is:
3 msec. 0 msec.
5311 EFB PAR11 Not used.
5314 EFB PAR14
5315 EFB PAR15
5317 EFB PAR17
Code Description
EFB Protocol Reference
Modbus N2 FLN
