15
Feedback from the Drive – EFB
Actual Value Scaling
The scaling of actual values can be protocol dependent. In general, for Actual
Values, scale the feedback integer using the parameter’s resolution. (See
"Parameter Descriptions" section in ACH550 User’s Manual for parameter
resolutions.) For example:
Where parameters are in percent, the "Parameter Descriptions" section specifies
what parameter corresponds to 100%. In such cases, to convert from percent to
engineering units, multiply by the value of the parameter that defines 100% and
divide by 100%. For example:
1. Assuming, for the sake of this example, that the Actual Value uses parameter 9908 MOT NOM SPEED
as the 100% reference, and that 9908 = 1500 rpm.
2. Assuming, for the sake of this example, that the Actual Value uses parameter 9907
MOT NOM FREQ
as the 100% reference, and that 9907 = 500 Hz.
Although Actual Value scaling could differ from the above for the N2 and FLN
protocols, it currently does not. To confirm, see the following sections, as
appropriate:
• "N2 Analog Input Objects" in the "N2 Protocol Technical Data" section.
• "Scaling Drive Feedback Values" in the "FLN Protocol Technical Data" section.
Feedback
Integer
Parameter
Resolution
(Feedback Integer) * (Parameter Resolution) = Scaled Value
1 0.1 mA 1 * 0.1 mA = 0.1 mA
10 0.1% 10 * 0.1% = 1%
Feedback
Integer
Parameter
Resolution
Value of the
Parameter that
defines 100%
(Feedback Integer) * (Parameter Resolution) *
(Value of 100% Ref.) / 100% = Scaled Value
10 0.1% 1500 rpm
1
10 * 0.1% * 1500 RPM / 100% = 15 rpm
100 0.1% 500 Hz
2
100 * 0.1% * 500 Hz / 100% = 50 Hz
