FLN Protocol Technical Data
a. Points not listed are not used in this application.
b. A single value in a column means that the value is the same in English units and in SI units.
c. Point numbers that appear in brackets { } may be unbundled at the field panel.
66 LDO SPD OUT MIN 0 PCT 0.1 0 - -
67 LDO SPD OUT MAX 1000 PCT 0.1 0 - -
{68} LDO FLN LOC CTL AUTO - 1 0 FLN AUTO
{69} LDO FLN LOC REF AUTO - 1 0 FLN AUTO
{70} LDI DI 1 ACTUAL OFF - 1 0 ON OFF
{71} LDI DI 2 ACTUAL OFF - 1 0 ON OFF
{72} LDI DI 3 ACTUAL OFF - 1 0 ON OFF
{73} LDI DI 4 ACTUAL OFF - 1 0 ON OFF
{74} LDI DI 5 ACTUAL OFF - 1 0 ON OFF
{75} LDI DI 6 ACTUAL OFF - 1 0 ON OFF
{76} LDI RO 1 ACTUAL OFF - 1 0 ON OFF
{77} LDI RO 2 ACTUAL OFF - 1 0 ON OFF
{78} LDI RO 3 ACTUAL OFF - 1 0 ON OFF
{79} LDI RO 4 ACTUAL OFF - 1 0 ON OFF
{80} LDI RO 5 ACTUAL OFF - 1 0 ON OFF
{81} LDI RO 6 ACTUAL OFF - 1 0 ON OFF
{82} LAI AI 1 ACTUAL 0 PCT 0.1 0 - -
{83} LAI AI 2 ACTUAL 0 PCT 0.1 0 - -
{84} LAI AO 1 ACTUAL 0 MA 0.1 0 - -
{85} LAI AO 2 ACTUAL 0 MA 0.1 0 - -
{86} LDI OK.ALARM OK - 1 0 ALARM OK
{87} LDI OK.MAINT OK - 1 0 MAINT OK
{88} LAI ALARM WORD 1 - - 1 0 - -
{89} LAI ALARM WORD 2 - - 1 0 - -
{90} LAI LAST FAULT - - 1 0 - -
{91} LAI PREV FAULT 1 - - 1 0 - -
{92} LAI PREV FAULT 2 - - 1 0 - -
{93} LDI OK.FAULT OK - 1 0 FAULT OK
{94} LDO RESET FAULT NO - 1 0 RESET NO
{95} LAO MBOX PARAM - - 1 0 - -
{96} LAO MBOX DATA - - 1 0 - -
{97} LDO MBOX READ DONE - 1 0 READ DONE
{98} LDO MBOX WRITE DONE - 1 0 WRITE DONE
{99} LAO ERROR STATUS - - 1 0 - -
FLN Point Database
Point
Subpoint Name
Factory
Default
Engr.
Units
Slope Intercept
On Text Off Text
# Type (SI Units)
