24 Quick start-up
Operating instructions
The solar pump inverter is developed using the ACS355 firmware. Install the inverter as
defined in sections Mechanical installation, Installing power cables, and Installing control
cables. Before operating the inverter, set the required parameters defined in the following
steps.
If the inverter power rating matches the motor power rating, the inverter is ready to run. If
any parameter tuning such as acceleration and deceleration times, maximum and
minimum speeds, and so on is required, see ACS355 User’s manual
(3AUA0000066143 [English]).
Step Action Additional information
1 Install the solar pump inverter. See section Mechanical installation in
ACS355 User’s manual
(3AUA0000066143 [English]).
2 Connect the AC/DC input and motor cables
and the control cables.
See section Connecting the power cables
and Connecting the control cables in
ACS355 User’s manual
(3AUA0000066143 [English]).
3 Enter the commissioning data parameters in
99 START-UP DATA.
See section 99 START-UP DATA in
ACS355 User’s manual
(3AUA0000066143 [English]).
4 Set the basic application data using either
the control panel or the Drive window light
PC tool application:
Group 10 START/STOP/DIR
Group 11 REFERENCE SELECT
Group 20 LIMITS
Group 21 START/STOP
Group 60 PUMP CONTROL
Group 61 FLOW CALCULATION
Group 99 START-UP DATA
See section Control panels in ACS355
User’s manual
(3AUA0000066143 [English]).
The inverter is supported by version 2.91
or later of the Drive Window Light 2 PC
tool which includes a graphical Sequence
programming tool.
5 Monitor the inverter signals in Group 01
OPERATING DATA.
See section Actual Signals in ACS355
User’s manual
(3AUA0000066143 [English]).
