Actual signals and parameters 61
6124 FLOW CAL
GAIN
Defines the flow calculation gain for possible
calculation correction.
100 = 1
0.50...2.00 Gain value 1
6131 RESET FLOW Resets the measured flow data of actual signals to
zero in 0184 TODAY FLOW and 0185 CUMULA YEAR
FLOW.
DONE
DONE Flow reset is done. 0
RESET Activates the flow reset. 1
99 START-UP DATA
Defines special start-up data required to set up the
inverter and allows to enter motor information.
Note: All languages are not available for printing this
manual because language list typically change as time
passes.
9902 APPL MACRO Selects the application macros. See Application
macros in ACS355 User’s manual (3AUA0000066143
[English]).
ABB
STANDARD
ABB
STANDARD
Standard macro for solar mode. 1
3-WIRE 3-wire macro for constant speed applications. 2
ALTERNATE Alternate macro for start forward and start reverse
applications.
3
MOTOR POT Motor potentiometer macro for digital signal speed
control applications.
4
HAND/AUTO Hand/Auto macro used when two control devices are
connected to the inverter:
• Device 1 communicates through the interface
defined by external control location EXT1.
• Device 2 communicates through the interface
defined by external control location EXT2.
Note: Either EXT1 or EXT2 is active at a time. The
switching between EXT1 or EXT2 happens through
digital input.
5
PID CONTROL PID control for applications in which the inverter
controls a process value.
Example: For pressure controlled by the inverter
running a pressure boost pump, the measured
pressure and reference pressure are connected to the
inverter.
6
TORQUE CTRL Torque control macro. 8
All parameters
No. Name/
Value
Description Def/ FbEq
