72 Technical data
UL checklist
• The ACS355 drive is an IP20 (UL open or NEMA 1 type) drive to be used in a heated,
indoor controlled environment. The drive must be installed in clean air according to
enclosure classification. Cooling air must be clean, free from corrosive materials and
3-phase supply voltage 200 to 240 V units
ACS355-03X-03A5-2 R0 10 10 10
ACS355-03X-04A7-2 R1 10 10 10
ACS355-03X-06A7-2 R1 16 10 10
ACS355-03X-07A5-2 R1 16 16 10
ACS355-03X-09A8-2 R2 16 16 16
ACS355-03X-13A3-2 R2 25 25 25
ACS355-03X-17A6-2 R2 25 35 25
ACS355-03X-24A4-2 R3 63 35 35
ACS355-03X-31A0-2 R4 80 50 50
ACS355-03X-46A2-2 R4 100 80 63
3-phase supply voltage 380 to 480 V units
ACS355-03X-01A9-4 R0 10 10 10
ACS355-03X-02A4-4 R1 10 10 10
ACS355-03X-03A3-4 R1 10 10 10
ACS355-03X-04A1-4 R1 16 10 10
ACS355-03X-05A6-4 R1 16 10 10
ACS355-03X-07A3-4 R1 16 16 10
ACS355-03X-08A8-4 R1 20 25 16
ACS355-03X-12A5-4 R3 25 25 16
ACS355-03X-15A6-4 R3 35 35 25
ACS355-03X-23A1-4 R3 50 50 35
ACS355-03X-31A0-4 R4 80 63 50
ACS355-03X-38A0-4 R4 100 80 50
ACS355-03X-44A0-4 R4 100 80 63
Type code Frame size IEC Fuse AC side DC Fuse PV side
Fuse [A]
Type gG
Fuse Type
UR gG
