ABB ACS355-01E-06A7-2 [35/76] Settings

Program features 35

The cleaning sequence can be activated only in the manual mode of operation. The

cleaning sequence starts in the forward direction and follows the reverse direction. This

cycle repeats three times. If any intermediate fault occurs, the pump cleaning function

stops.

 Settings

Excluded functions

The following features of ACS355 firmware are not supported in the solar pump inverter.

• Timer and counter

• Frequency input

• Sequential programming

• Jogging

• Constant speed

• IR compensation

• Mechanical brake

Parameter Additional information

6021 PMP CLEAN SELECT

Initiates pump cleaning sequence.

6022 PMP CLEAN SPEED

Speed at which the pump cleaning sequence is initiated.

6023 PMP CLEAN TIME

Pump cleaning time.
