Actual signals and parameters 41
4 DEV_OVERTEMP 1 Drive IGBT temperature
is excessive.
0 Drive IGBT temperature
is within limit.
5 ID_RUN_FAIL 1 Motor ID run is not
completed successfully.
0 Motor ID run is
completed successfully.
6 OUTP_WIRING 1 Incorrect input power and
motor cable connection.
0 Correct input power and
motor cable connection.
7 SAFE_TORQUE_
OFF
1 STO (Safe torque off) is
active.
0 STO (Safe torque off) is
not active.
8 MOT_OVERTEMP 1 Motor temperature
estimation is beyond
limit.
0 Motor temperature
estimation is within limit.
9 START_ENABLE 1 Start enable signal
received.
0 No start enable signal
received.
10 RUN_ENABLE 1 Run enable is activated.
0 Run enable is not
activated.
11 CONFIG_FILE 1 Internal configuration file
error detected.
0 No internal configuration
file error detected.
12...
15
Reserved
Actual signals
No. Name/Value Description FbEq
