on the jug lid aached to the blender jug must point toward the jug handle and the jug

spout, respecvely (Fig. 6).

6. Grasp the blender housing with one hand. Li the swivel blender top ❷ with the other

hand into the posion shown in Fig. 7.

7. Put the blender jug ❼ in the blender housing ❶ with the jug handle aligned with the

open padlock mark. Now, twist the blender jug gently to align the jug handle with the

closed padlock mark (Fig. 8). With the blender jug installed, lower and press the swivel

blender top to lock it in place (Fig. 9).

8. The blender jug is removed from the blender hous-

ing in the reverse order of assembly: li the swivel

blender top ❷, twist the blender jug to align the jug

handle with the open padlock mark, and remove the

blender jug from the blender housing (Fig. 10). Re-

move the blender jug lid and the blade rotor.

INSTALLING THE PORTABLE PITCHER

1. Install the rubber valve ⓭ in the portable pitcher lid

top ⓰. The rubber valve stem end must pass clear

all around through the underside of the lid. Place

the portable pitcher lid gasket ⓯ underneath the portable pitcher lid. Align the gasket

notches with the respecve bosses under the portable pitcher lid.

2. Twist on the valve lter ❿ snugly to the boom of the portable pitcher lid ⓰.

3. Close the portable pitcher ⓮ with the lid ⓰.

4. Open the swivel blender top ❷, place the portable pitcher ⓰ in the blender housing

and close the swivel blender top ❷. You can only vacuum the portable pitcher. You

cannot blend the contents. The blender motor funcons are locked out; if you aempt

to operate any blending-related control, Error E1 will be displayed.

Fig. 7 Fig. 8 Fig. 9

Fig. 10
