powered down, reset on the keypad or by re-
enabling the drive.
P-31
Keypad mode
restart function
0 : Minimum speed
1 : Previous speed
2 : Minimum speed (Auto-run)
3 : Previous speed (Auto-run)
1
If set to 0 or 2, drive will always start from
minimum speed.
If set to 1 or 3, drive ramps up to the operating
speed prior to the last STOP command.
If set to 2 or 3, the status of digital input 1
controls drive to start or stop. The start and
stop button on the drive will not function in this
case.
P-32
DC injection on
stop
0 to 25.0s
0
(disabled)
When > 0, DC injection braking activated when
speed reaches zero with stop signal applied.
Only applied on disable (Stop), not on enable.
Uses the level set in P-11.
P-33
Spin Start (S2 & S3
only)
DC injection on
start (S1)
0 : Disabled
1 : Enabled
0
When enabled, drive starts from detected
motor rotor speed. Short start delay possible if
rotor stationary. Recommended for high inertia
load applications.
For Size 1 drives, P-33 = 1 enables DC
injection braking on enable. The duration and
levels are set by P-32 and P-11 respectively.
P-34
Brake chopper
enable
(not S1)
0 : Disabled
1 : Enabled with s/w protection
2 : Enabled without s/w
protection
0
Software protection for Invertek standard brake
resistors (200W).
For Non-Invertek approved resistors and higher
braking applications set to 2.
P-35
Analog input
scaling
0 … 500.0% 100% Analog input scaling, resolution 0.1%.
Serial
Communications
address
Adr : 0 disable, 1..63 1
MODBUS enable /
baudrate select
OP-buS (fixed at 115.2 kbps)
9.6k to 115.2kbps (Modbus)
0P-buS
P-36
Trip enable / delay
0 (no trip),
t 30, 100, 1000, 3000 (ms)
Adr : Unique drive address for communication
network
When set to OP-buS, MODBUS disabled.
Communication with PDA, PC and Optiport E2
possible
Setting a baudrate enables MODBUS at that
baudrate and disables OP-buS.
The time before a trip in the event of a
communication loss can be set in milliseconds.
Setting “0” disables the communications trip.
t 3000
(3 second
trip)
r 30, 100, 1000, 3000 (ms))
“t” indicates the drive will trip if time exceeded.
“r” indicates the drive will ramp to stop if time
exceeded.
P-37
Access code
definition
0 to 9 999 101
Defines Extended Parameter Set access code,
P-14
P-38
Parameter access
lock
0: Parameters can be changed
& automatically saved on
power down
1: Read-only. No changes
allowed.
0
Controls user access to parameters. When P-
38 = 0, all parameters can be changed and will
be stored automatically. When P-38 = 1,
parameters are locked and cannot be changed.
Introduces an offset to the analog input level
with a resolution 0.1%. e.g. 10% = 1V = 0Hz
P-39 Analog input offset -500.0 … 500.0% 0%
Custom scaling factor applied to drive speed. If
P-10 = 0, speed in Hz scaled by this factor. If
P-10 > 0, speed in RPM scaled. Displayed as
real-time variable on the drive display,
indicated by a “c”.
P-40
Display speed
scaling factor
0.000 to 6.000
P-41
User PI
Proportional Gain
0.0 ... 30.0 1.0
Higher value used for high inertia. Too high a
value gives instability.
P-42
User PI Integral
time constant
0.0s ... 30.0s 1.0s
Higher value gives slower, more damped
response.
If an increasing feedback signal should
increase the speed of the motor, set to
‘Inverse’ mode.
P-43
User PI operating
mode
0: Direct
1: Inverse
0
P-44
User PI reference
select
0: Digital
1: Analog
0
Sets the source for the PI control reference
signal. When set to 1, analog input 1 is used.
P-45
User PI digital
reference
0 … 100% 0.0 % Sets the preset reference used when P-44 = 0.
P-46
User PI feedback
select
0 : 2nd analog input (T4)
1 : 1st analog input (T6)
2 : motor load current
0
This parameter selects the feedback signal
source.
0 ..10V
Selects the format of the 2nd analog input.
P-47
2nd analog input
format
0..10V, 0..20mA,
t 4..20mA, r 4..20mA,
t 20..4mA r 20..4mA
“t” indicates the drive will trip if signal removed
when drive is enabled.
“r” indicates the drive will ramp to Preset Speed
1 if signal is removed when the drive is enabled
Optidrive E2 IP55/NEMA 12 User Guide
www.invertek.co.uk
17
