Invertek Drives ODV-42075-IN [23/24] Rating tables
![Invertek Drives ODV-42075-IN [23/24] Rating tables](/views2/1583407/page23/bg17.png)
10.2. Rating tables
110-115V ±10% - 1 Phase Input - 3 Phase 230V Output (Voltage Doubler)
kW HP Frame
Size
Nominal
Input
Current
Fuse or
MCB
(type B)
Supply
Cable
Size
Nominal
Output
Current
150%
Output
Current
60 secs
Motor
Cable
Size
Max
Motor
Cable
Length
Min
Brake
Res
Value
Amps Amps mm
2
Amps Amps mm
2
m Ω
- 0.5 1 6.7 10 1.5 2.3 3.45 1.5 25 -
- 1 1 12.5 16(15)* 1.5 4.3 6.45 1.5 25 -
- 1.5 2 16.8 20 2.5 5.8 8.7 1.5 100 47
200-240V ±10% - 1 Phase Input – 3 Phase Output
kW HP Frame
Size
Nominal
Input
Current
Fuse or
MCB
(type B)
Supply
Cable
Size
Nominal
Output
Current
150%
Output
Current
60 secs
Motor
Cable
Size
Max
Motor
Cable
Length
Min
Brake
Res
Value
Amps Amps mm
2
Amps Amps mm
2
m Ω
0.37 0.5 1 6.7 6 1.5 2.3 3.45 1.5 25 -
0.75 1 1 12.5 10 1.5 4.3 6.45 1.5 25 -
1.5 2 1 19.3 20 4 7 10.5 1.5 25 -
1.5 2 2 19.3 20 4 7 10.5 1.5 100 47
2.2 3 2 28.8 32(35)* 4 10.5 15.75 1.5 100 47
200-240V ±10% - 3 Phase Input – 3 Phase Output
kW HP Frame
Size
Nominal
Input
Current
Fuse or
MCB
(type B)
Supply
Cable
Size
Nominal
Output
Current
150%
Output
Current
60 secs
Motor
Cable
Size
Max
Motor
Cable
Length
Min
Brake
Res
Value
Amps Amps mm
2
Amps Amps mm
2
m Ω
0.37 0.5 1 3 6 1.5 2.3 3.45 1.5 25 -
0.75 1 1 5.8 10 1.5 4.3 6.45 1.5 25 -
1.5 2 1 9.2 16(15)* 2.5 7 10.5 1.5 25 -
1.5 2 2 9.2 16(15)* 2.5 7 10.5 1.5 100 47
2.2 3 2 13.7 20 4 10.5 15.75 1.5 100 47
4.0 5 3 20.7 32(35)* 4 18 27 2.5 100 47
380-480V ±10% - 3 Phase Input – 3 Phase Output
kW HP Frame
Size
Nominal
Input
Current
Fuse or
MCB
(type B)
Supply
Cable
Size
Nominal
Output
Current
150%
Output
Current
60 secs
Motor
Cable
Size
Max
Motor
Cable
Length
Min
Brake
Res
Value
Amps Amps mm
2
Amps Amps mm
2
m Ω
0.75 1 1 2.9 5 1.5 2.2 3.3 1.5 25 -
1.5 2 1 5.4 10 1.5 4.1 6.15 1.5 25 -
1.5 2 2 5.4 10 1.5 4.1 6.15 1.5 100 47
2.2 3 2 7.6 10 1.5 5.8 8.7 1.5 100 47
4 5 2 12.4 16(15)* 2.5 9.5 14.25 1.5 100 47
5.5 7.5 3 16.1 20 2.5 14 21 2.5 100 22
7.5 10 3 17.3 20 4 18 27 2.5 100 22
Output Frequency range: 0 - P-01 (500Hz max)
For UL compliance Motor Cable to be Copper 75C and Fuse current rating defined by ratings marked ( )*
10.3. Maximum supply ratings for UL compliance:
Drive rating Maximum supply voltage Maximum supply
short-circuit current
115V ratings –
0.5 HP to 1.5HP
120V rms (AC) 5kA rms (AC)
230V ratings –
0.37kW (0.5HP) to 3.7kW (5HP)
240V rms (AC) 5kA rms (AC)
400/460V ratings –
0.75kW(1HP) to 7.5kW(10HP)
480V rms (AC) 5kA rms (AC)
All the drives in the above table are suitable for use on a circuit capable of delivering not more than the above specified maximum
short-circuit Amperes symmetrical with the specified maximum supply voltage.
Optidrive E2 IP55/NEMA 12 User Guide
www.invertek.co.uk
23
