7.2. Extended parameters
Par. Description Range Default Explanation
P-15
Digital input
function select
0 to 12 0
Defines the function of the digital inputs
depending on the control mode setting in P-12.
See section
8 Analog and Digital Input
Configurations
for more information.
P-16 Analog input format
0..10V, b 0..10V, 0..20mA,
t 4..20mA, r 4..20mA,
t 20..4mA r 20..4mA
0..10V
Configures the voltage or current format of the
analog input signal.
b 0..10V can be used for bipolar input signals. A
50% offset can be applied to P-39 and 200%
scaling in P-35 gives ± P-01
“t” indicates the drive will trip if signal removed
when drive is enabled.
“r” indicates the drive will ramp to Preset Speed 1
if signal is removed when drive is enabled
P-17
Effective switching
frequency
4 .. 32kHz 8 / 16kHz
Sets maximum effective switching frequency of
the drive. If “rEd” is displayed, the switching
frequency has been reduced to the level in P00-
14 due to excessive drive heatsink temperature.
P-18
User relay output
select
0 : Drive enabled
1 : Drive healthy
2 : Motor at target speed
3 : Drive tripped
4 : Motor speed >= limit
5 : Motor current >= limit
6 : Motor speed < limit
7 : Motor current < limit
1
Defines the function of the user relay, when the
operating conditions are met.
Disabled : Contacts open
Enabled : Contacts closed
Options 4 to 7: the Relay output is enabled
using the level set in P-19
P-19
User relay output
limit
0.0 to 100% for speed
0.0 to 200% for current
100% Sets the limit for P-18 & P-25
P-20 Preset speed 1 -P-01 to P-01 0 Hz Sets jog / preset speed 1
P-21 Preset speed 2 -P-01 to P-01 0 Hz Sets jog / preset speed 2
P-22 Preset speed 3 -P-01 to P-01 0 Hz Sets jog / preset speed 3
P-23 Preset speed 4 -P-01 to P-01 0 Hz Sets jog / preset speed 4
P-24
2nd decel ramp
time
(Fast Stop)
0…25.0s 0
2nd Deceleration ramp time from base speed
(P-09) to standstill in seconds.
Selected using fast stop function via digital
input setting or on mains loss as set by P-05
If set to zero drive will coast to STOP.
P-25
Analog output
function select
Digital output mode
0 : Drive enabled
1 : Drive healthy
2 : Motor at target speed
3 : Drive tripped
4 : Motor speed >= limit
5 : Motor current >= limit
6 : Motor speed < limit
7 : Motor current < limit
Analog output mode
8 : Motor speed
9 : Motor current
8
Digital Output Mode
Options 0 to 7 select a digital voltage output
signal
Disabled : 0V
Enabled : +24V, (20mA limit)
Options 4 to 7 : the Digital output is enabled
using the level set in P-19
Analog Output Mode
Option 8 : Motor Speed signal range
0..10V = 0..100% of P-01
Option 9 : Motor Current signal range
0..10V = 0..200% of P-08
P-26
Skip frequency
hysteresis band
0 to P-01 0 Hz
Set P-09 before adjusting.
Speed reference held at upper or lower skip
frequency limit until input signal reaches the
opposite skip frequency limit. Speed ramps
through the skip frequency band at a rate set
by P-03 and P-04.
P-27 Skip frequency P-02 to P-01 0 Hz
Set P-09 before adjusting.
Skip frequency centre point
P-28
V/F characteristic
adjustment voltage
0 … P-07 0
Adjusts the applied motor voltage to this value
at the frequency set in P-29
P-29
V/F characteristic
frequency adjust
0 … P-09 0.0Hz
Sets the frequency at which the adjustment
voltage set in P-28 is applied
P-30
Terminal mode
restart function
EdgE-r, Auto-0 .. Auto-5 Auto-0
Edge-r : if drive is powered up with Digital Input
1 closed (enabled), drive will not run. The
switch must be opened & closed after power up
or after clearing a trip for the drive to run.
Auto-0 : drive will run whenever digital input 1
is closed (if not tripped).
Auto-1..5 : drive will make 1..5 attempts to
automatically restart after a trip (25s between
attempts). If fault has cleared drive will restart.
To reset the counter the Drive must be
16 Optidrive E2 IP55/NEMA 12 User Guide
