Technical data of the pump
Technical data of an Etaline pump
Size Shaft unit Impeller Speed limit
Impeller
outlet width
Impeller inlet
diameter
Impeller diameter Maximum Minimum
Maximum Minimum
[mm] [mm] [mm] [mm] [rpm] [rpm]
032-032-160 WS_25 5,7 52,7 170 112 4400 500
032-032-200 WS_25 5,6 54,0 204 165 3800 500
040-040-160 WS_25 8,5 60,6 174 136 3500 500
040-040-250 WS_25 7,5 62,6 261 197 3000 500
050-050-160 WS_25 13,0 70,0 174 120 4400 500
050-050-250 WS_25 8,4 74,1 260 198 3000 500
065-065-160 WS_25 16,9 86,9 174 108 4400 500
065-065-250 WS_25 10,5 84,0 260 196 3000 500
080-080-160 WS_25 21,0 92,0 174 132 3900 500
080-080-200 WS_25 17,0 99,7 219 170 3000 500
080-080-250 WS_35 15,1 101,0 260 190 3000 500
100-100-125 WS_25 25,8 99,0 141 124 4000 500
100-100-160 WS_25 31,6 124,0 174 138 3500 500
100-100-200 WS_35 24,5 115,0 219 178 3500 500
100-100-250 WS_35 19,0 115,0 269 215 2900 500
125-125-160 WS_35 37,6 135,0 185 155 3600 500
125-125-200 WS_35 32,5 142,0 219 179 3300 500
125-125-250 WS_35 27,0 145,0 269 210 2500 500
150-150-200 WS_35 40,7 159,0 224 178 2600 500
150-150-250 WS_35 37,0 162,4 269 218 2000 500
200-200-250 WS_35 48,8 191,0 269 220 1800 500
200-200-315 WS_55 39,7 191,5 334 264 2100 500
Technische Daten Etaline-R
Size Shaft unit Impeller Speed limit
Impeller
outlet width
Impeller inlet
diameter
Impeller diameter Maximum Minimum
Maximum Minimum
[mm] [mm] [mm] [mm] [rpm] [rpm]
150-500 WE65 21,0 200 410 500 1500 300
200-330 WE65 54,0 220 270 330 1800 300
200-400 WE65 38,0 240 340 405 1800 300
200-500 WE65 36,0 220 420 510 1500 300
250-250 WE65 57,0 213 200 240 1800 300
250-260 WE65 62,0 190 240 260 1800 300
250-300 WE65 66,5 248 245 285 1800 300
250-330 WE65 72,0 240 290 330 1800 300
250-400 WE65 58,0 280 340 405 1800 300
250-500 WE65 44,0 260 440 520 1500 300
300-360 WE65 78,0 260 320 360 1800 300
300-400 WE65 65,0 290 360 430 1800 300
300-500 WE65 56,0 290 450 520 1500 300
Heating / Air-conditioning / Ventilation
In-line Pumps
14
Etaline / Etaline-R
