![KSB Etaline ETL-350-340/7504 280S [72/90] Etaline etaline r](/img/pdf.png)
KSB Etaline ETL-350-340/7504 280S [72/90] Etaline etaline r
![KSB Etaline ETL-350-340/7504 280S [72/90] Etaline etaline r](/views2/1585123/page72/bg48.png)
Pump size Motor DN
1
17)
a ≈b
1
18)
≈b
2
18)
d
1
d
2
d
3
p h
1
h
2
≈I
1
18)
≈I
2
18)
t ≈x
18)
w m
1
m
2
o
[KW] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm]
125-125-160 2,2 125 203 182 226 M20 250 213 135 420 280 740 537 25 140 190 - - -
125-125-160 3,0 125 203 182 226 M20 250 213 135 420 280 775 572 25 140 190 - - -
125-125-160 4,0 125 203 182 226 M20 250 234 148 420 280 764 561 25 140 190 - - -
125-125-160 5,5 125 203 182 226 M20 300 266 167 420 280 829 626 25 140 213 - - -
125-125-160 7,5 125 203 182 226 M20 300 298 167 420 280 857 654 25 140 213 - - -
125-125-200 3,0 125 206 175 214 M20 250 213 135 380 320 778 572 25 140 190 - - -
125-125-200 4,0 125 206 175 214 M20 250 234 148 380 320 767 561 25 140 190 - - -
125-125-200 5,5 125 206 175 214 M20 300 266 167 380 320 832 626 25 140 213 - - -
125-125-200 7,5 125 206 175 214 M20 300 298 167 380 320 860 654 25 140 213 - - -
125-125-200 11,0 125 206 175 214 M20 350 325 197 380 320 998 792 25 140 246 - - -
125-125-200 15,0 125 206 175 214 M20 350 325 197 380 320 1004 798 25 140 246 - - -
125-125-250 5,5 125 210 188 219 M20 300 266 167 380 320 836 626 25 140 213 - - -
125-125-250 7,5 125 210 188 219 M20 300 298 167 380 320 864 654 25 140 213 - - -
125-125-250 11,0 125 210 188 219 M20 350 325 197 380 320 1002 792 25 140 246 - - -
125-125-250 15,0 125 210 188 219 M20 350 325 197 380 320 1008 798 25 140 246 - - -
125-125-250 18,5 125 210 188 219 M20 350 370 262 380 320 1066 856 25 140 246 - - -
125-125-250 22,0 125 210 188 219 M20 350 370 262 380 320 1066 856 25 140 246 - - -
150-150-200 5,5 150 230 187 240 M20 300 266 167 385 315 856 626 25 140 213 - - -
150-150-200 7,5 150 230 187 240 M20 300 298 167 385 315 884 654 25 140 213 - - -
150-150-200 11,0 150 230 187 240 M20 350 325 197 385 315 1022 792 25 140 246 - - -
150-150-200 15,0 150 230 187 240 M20 350 325 197 385 315 1028 798 25 140 246 - - -
150-150-200 18,5 150 230 187 240 M20 350 370 262 385 315 1086 856 25 140 246 - - -
150-150-250 7,5 150 222 226 275 M20 300 298 167 370 330 891 669 25 140 228 - - -
150-150-250 11,0 150 222 226 275 M20 350 325 197 370 330 1029 807 25 140 261 - - -
150-150-250 15,0 150 222 226 275 M20 350 325 197 370 330 1035 813 25 140 261 - - -
150-150-250 18,5 150 222 226 275 M20 350 370 262 370 330 1093 871 25 140 261 - - -
150-150-250 22,0 150 222 226 275 M20 350 370 262 370 330 1093 871 25 140 261 - - -
150-150-250 30,0 150 222 226 275 M20 400 422 305 370 330 1152 930 25 140 261 - - -
150-150-250 37,0 150 222 226 275 M20 450 460 325 370 330 1209 987 25 140 292 - - -
200-200-250 11,0 200 222 233 303 M20 350 325 197 400 400 1067 845 25 140 299 - - -
200-200-250 15,0 200 222 233 303 M20 350 325 197 400 400 1073 851 25 140 299 - - -
200-200-250 18,5 200 222 233 303 M20 350 370 262 400 400 1131 909 25 140 299 - - -
200-200-250 22,0 200 222 233 303 M20 350 370 262 400 400 1131 909 25 140 299 - - -
200-200-250 30,0 200 222 233 303 M20 400 422 305 400 400 1190 968 25 140 299 - - -
200-200-250 37,0 200 222 233 303 M20 450 460 325 400 400 1247 1025 25 140 330 - - -
200-200-250 45,0 200 222 233 303 M20 450 468 325 400 400 1277 1055 25 140 330 - - -
200-200-315 22,0 200 255 259 318 M20 350 370 262 490 410 1141 886 25 140 276 - - -
200-200-315 30,0 200 255 259 318 M20 400 422 305 490 410 1200 945 25 140 276 - - -
200-200-315 37,0 200 255 259 318 M20 450 460 325 490 410 1257 1002 25 140 307 - - -
200-200-315 45,0 200 255 259 318 M20 450 468 325 490 410 1287 1032 25 140 307 - - -
200-200-315 55,0 200 255 259 318 M20 550 520 392 490 410 1391 1136 25 140 319 - - -
17)
DN = EN 1092-2, PN 16
18)
For the exact motor-related dimensions refer to the general arrangement drawing.
Heating / Air-conditioning / Ventilation
In-line Pumps
72
Etaline / Etaline-R
