High Performance Vector Control/Torque Control Inverter User Manual
84 Chapter 6 Parameter Description
Under torque control, when the terminal function is valid, the speed limiting is Pd.06 and Pd.07. When
the terminal function is invalid, the speed limiting is determined by the corresponding analog channel.
Refer to the description of the relevant analog channel of P6.21.
66 Zero servo enable terminal
When this function is valid, the inverter enters zero servo status. For the zero servo functions, refer to the
description of the relevant zero servo functions of Pd.25 to Pd.27.
67: Closed loop output forced to be 0
Under process closed loop control or composite control, when the terminal is valid, the output frequency
of the inverter process closed loop adjustment is forced to set as 0.
68: PID positive or negative function
PID is positeve function at default. It needed negative function when feedback value is greater than
reference value and the frequency needed increase. This function can realized through setting P8.09=1
or multi-function terminal function setting as 68.
P8.09=0, Terminal function is invalid: Positive;
P8.09=1, Terminal function is valid: Positive;
P8.09=1, Terminal function is invalid: Negative;
P8.09=0，Terminal function is valid: Negative.
69 to 98: Reserved
It can properly enlarge the setup value of P5.07 to improve the anti-interference capability of the terminal.
The longer the terminal filter time is, the longer the delay time of the terminal action is.
When the pulse input of the multifunctional input terminal X7/DI acts as open loop frequency reference or
analog feedback close loop reference (e.g. P0.04=4 or P1.02=4), the maximum input pulse frequency
determined via this functional code.
When the pulse input acts as open loop frequency reference, maximum input pulse frequency P5.10
corresponds to maximum output frequency P0.11, the current pulse input frequency f
P
and open loop
frequency reference f can be calculated as per the following formula: f=f
P
× P0.11/ P5.10.
When the pulse input acts as close loop frequency reference, maximum input pulse frequency P5.10
corresponds to maximum digital voltage reference 10V, the current pulse input frequency f
P
and analog
feedback close loop reference V
P
can be calculated as per the following formula: v
P
=f
P
× 10V/ P5.10.
P5.11 is used to set the mode of controlling the startup and stop of the inverter with FWD and REV
terminals in the terminal running command reference mode.
P5.07 X1 to X7 terminal filtering time
0.000~1.000 s(0.001s)
P5.10 Maximum input pulse frequency
0.1~ 50.0 kHz (10.0 kHz)
P5.11 Startup/stop mode Selection
0 ~ 3(0)
