7-115
Chapter 7 ARP Configuration (Dynamic ARP Inspection)
7.1 Brief Introduction of ARP
ARP table is a table of the relationship between IP and MAC, including dynamic and static. Dynamic ARP table item
is learnt by ARP protocol. Static ARP table item is added manually.
7.2 ARP configuration
ARP configuration list
Configuration list is as following:
· Display ARP table item
· Enable/disable ARP anti-flood attack
· Configure deny action and threshold of ARP anti-flood
· Configure ARP anti-flood recover-time
· ARP anti-flood MAC recover
· Display ARP anti-flood attack information
· Enable/disable ARP anti-spoofing
· Configure unknown ARP packet handling strategy
· Enable/disable ARP anti-spoofing valid-check
· Enable/disable ARP anti-spoofing deny-disguiser
· Display ARP anti-spoofing
7.2.1 Display ARP table item
Use this command to display static, dynamic, specified IP address or all ARP table item.
Display all ARP table item：
QTECH(config)#show arp all
Display dynamic ARP table item：
QTECH(config)#show arp dynamic
Display static ARP table item：
