1-12
· RADIUS configuration mode
· Domain configuration mode
The function and details of each command mode are as following:
Table 1. Command Line Configuration Mode
Command line
mode
Function Prompt
character
Command for entering Command for exiting
User mode See switch
operation
information
QTECH>
Connect with switch after
inputting user name and
password
exit disconnect with switch
Privileged mode See switch
operation
information
and manage
system
QTECH#
Input enable in user mode exit return to user mode
quit disconnect with switch
Global
configuration mode
Configure
global
parameter
QTECH(con
fig)#
Input configure terminal in
privileged mode
exit, end return to privileged mode
quit disconnect with switch
Interface
configuration mode
Configure
interface
parameter
QTECH(con
fig-if-etherne
t-0/1)#
Input “interface Ethernet 0/1”
in global configuration mode,
interface configuration can
enter other interface mode and
VLAN configuration mode
without inputting “exit”.
VLAN
configuration mode
Configure
VLAN
parameter
QTECH(con
fig-if-vlan)#
Input “vlan 2” in global
configuration mode, VLAN
configuration mode can enter
other VLAN mode and
interface configuration mode
without inputting “exit”.
AAA configuration
mode
Create
domain
QTECH(con
fig-aaa)#
Input “aaa” in global
configuration mode
end return to privileged mode
exit return to global configuration
mode
quit disconnect with switch
RADIUS
configuration mode
Configure
RADIUS
server
parameter
QTECH(con
fig-radius-de
fault)#
Input “radius host default” in
global configuration mode
Domain
configuration mode
Configure
domain
parameter
QTECH(con
fig-aaa-test.c
om)#
Input “domain test.com” in
AAA configuration mode
end return to privileged mode
exit return to AAA configuration
mode
quit disconnect with switch
1.1.2 Command Syntax Comprehension
This chapter describes the steps needed for command configuration. Please read this section and related detail
information of command line interface in the following sections carefully.
The logging in identity verification of the system console of this switch is used to verify the identity of the
operating user. It permits and refuses the logging in by matching recognizing user name and password.
Step 1. Following are showed when entering command line interface,
Username(1-32 chars):
Please input user name, press Enter button, and then the prompt is as following:
Password (1-16 chars):
Input password. If it is correct, enter the user mode with the following prompt:
QTECH>
& Note: Defaulted login and password is admin/123456.
