10-153
no spanning-tree
By default, interface STP enables.
For example:
! Disable STP on Ethernet 01
QTECH(config-if-ethernet-0/1)#no spanning-tree
10.2.4 Configure STP priority
Configure STP priority when STP enables, and the inferior priority of the switch can be the root bridge. Use
following command in global configuration mode:
· Configure STP priority
spanning-tree priority bridge-priority
· Restore default STP priority
no spanning-tree priority
For example:
! Configure the priority of the switch in spanning tree to 30000
QTECH(config)#spanning-tree priority 30000
Caution: If the priorities of all network bridge in switching network are the same,
choose the one with the smallest MAC address to be the root. If STP enables, configuring
network bridge may cause the re-accounting of the STP. By default, the network bridge
priority is 32768 and ranges from 0 to 65535.
10.2.5 Configure switch Forward Delay
When this switch is the root bridge, port state transition period is the Forward Delay time, which is
determined by the diameter of the switched network. The longer the diameter is, the longer the time is. Configure it
in global configuration mode:
· Configure Forward Delay
spanning-tree forward-time seconds
· Restore default Forward Delay
no spanning-tree forward-time
For example:
! Configure forward delay to 20 seconds
QTECH(config)#spanning-tree forward-time 20
Caution: If Forward Delay is configured too small, temporary redundancy will becaused; if Forward Delay
is configured too large, network will not be restored linking for a long time. Forward Delay ranges from 4 to 30
seconds. The default forward delay time, 15 seconds is suggested to use. Forward Delay>=Hello Time + 2.
