8-124
Table 1 ACL number restriction
Standard ACL based on number ID 1-99 99
Extended ACL based on number ID 100-199 100
Layer 2 ACL based on number ID 200-299 100
User-defined ACL based on number ID 300-399 100
Standard ACL based on name ID -- 1000
Extended ACL based on name ID -- 1000
Layer 2 ACL based on name ID -- 1000
User-defined ACL based on name ID -- 1000
Sub-rule number which can be configured by an ACL 0-127 128
The max sub-rule number which can be configured -- 3000
Time range -- 128
The absolute time range which can be configured by a time range -- 12
The periodic time range which can be configured by a time range -- 32
Sub-item of activating ACL -- 1416
8.3 ACL configuration
8.3.1 Configuration list
ACL configuration includes:
· Configure time range
· Define ACL
· Activate ACL
Above three steps should be in order. Configure time range at first, then defaine ACL which will introduce
defined time range and activate ACL.
8.3.2 Configure time range
a) Enter time-range configuration mode
Use time-range command to enter time-range configuration mode. In this mode, you can configure time range.
Configure it in global configuration mode.
Command:
time-range time-range-name
